ASTM A335 P5 Pipe Specification
ASTM A335 P5 Pipe Sizes
Alloy Steel P5 Material Length
P5 Chrome Moly Pipe Applications
UNS K41545 Pipe Documentation
SA335 P5 Seamless Pipe End Types
Features of ASTM A335 P5 Pipe
P5 Alloy Steel Pipes Manufacturing Process
UNS K41545 Pipe Surface Finish
SA 335 Grade P5 Alloy Steel Seamless Pipes Packaging
ASTM A335 P5 Pipe Advantages
SA335 P5 Round Pipe Testing
Alloy Steel P5 Material Standards
Alloy Steel P5 Material Origins
Types of ASTM A335 P5 Pipe
Measurement of P5 Alloy Steel Pipes
ASTM A335 P5 Pipe Disadvantages
ASTM A335 P5 Pipe Supplier in China Provides a Wide Range of Regularly Used Pipe Types.
ASTM A335 P5 Pipe
Alloy Steel P5 Material
P5 Alloy Steel Pipes
SA 335 Grade P5 Alloy Steel Seamless Pipes
SA335 P5 Seamless Pipe
P5 Chrome Moly Pipe
A335 Grade P5 cold rolled pipe
UNS K41545 Pipe
SA335 P5 Round Pipe
Size Chart Of ASTM A335 P5 Pipe
ASTM A335 P5 Pipe Manufacturer in China Provides a Large Range of Diameters to Meet the Needs of Customers.
| ASTM A335 P5 SEAMLESS PPE OD MM |
Kg/m | PIPE WT MM |
SCH | IN. |
|---|---|---|---|---|
| 219.08 | 112.97 | 23.012) | 160 | 8 |
| 13.72 | 0.50 | 1.65 | 10S | 1/4 |
| 219.08 | 65.63 | 12.7 | 80S | 8 |
| 13.72 | 0.64 | 2.24 | 40S | 1/4 |
| 141.30 | 49.87 | 15.882) | 160 | 5 |
| 13.72 | 0.81 | 3.02 | 80S | 1/4 |
| 219.08 | 43.20 | 8.18 | 40S | 8 |
| 73.03 | 5.35 | 3.05 | 10S | 2½ |
| 17.15 | 1.12 | 3.20 | 80S | 3/8 |
| 21.34 | 1.02 | 2.11 | 10S | 1/2 |
| 101.60 | 18.92 | 8.08 | 80S | 3½ |
| 21.34 | 1.29 | 2.77 | 40S | 1/2 |
| 114.30 | 8.50 | 3.05 | 10S | 4 |
| 33.40 | 3.29 | 4.55 | 80S | 1 |
| 21.34 | 1.65 | 3.73 | 80S | 1/2 |
| 26.67 | 1.30 | 2.11 | 10S | 3/4 |
| 48.26 | 5.49 | 5.08 | 80S | 1½ |
| 26.67 | 1.71 | 2.87 | 40S | 3/4 |
| 60.33 | 3.99 | 2.77 | 10S | 2 |
| 26.67 | 2.23 | 3.91 | 80S | 3/4 |
| 60.33 | 11.29 | 8.742) | 160 | 2 |
| 33.40 | 2.13 | 2.77 | 10S | 1 |
| 101.60 | 13.78 | 5.74 | 40S | 3½ |
| 73.03 | 11.59 | 7.01 | 80S | 2½ |
| 141.30 | 31.44 | 9.53 | 80S | 5 |
| 33.40 | 2.54 | 3.38 | 40S | 1 |
| 141.30 | 22.10 | 6.55 | 40S | 5 |
| 33.40 | 4.30 | 6.352) | 160 | 1 |
| 42.16 | 2.73 | 2.77 | 10S | 1¼ |
| 168.28 | 14.04 | 3.4 | 10S | 6 |
| 48.26 | 4.11 | 3.68 | 40S | 1½ |
| 73.03 | 8.77 | 5.16 | 40S | 2½ |
| 168.28 | 68.59 | 18.262) | 160 | 6 |
| 88.90 | 6.56 | 3.05 | 10S | 3 |
| 88.90 | 21.67 | 11.132) | 160 | 3 |
| 101.60 | 7.53 | 3.05 | 10S | 3½ |
| 219.08 | 91.30 | 18.23 | 120 | 8 |
Alloy Steel P5 Material Thickness Chart
| NPS [DN] DESIGNATOR | TOLERANCE, % FROM SPECIFIED | |
|---|---|---|
| OVER | UNDER | |
| Above 2 1/2 [65], t/D > 5% | 15.0% | 12.5% |
| Above 2 1/2 [65], t/D < or = 5% | 22.5% | 12.5% |
| 1/8 to 2 1/2 [6 to 65] incl., all t/D ratios | 20.0% | 12.5% |
SA 335 Grade P5 Alloy Steel Pipe Weight Chart
| SIZE NPS | WEIGHT PER FOOT | PIPE O.D. | PIPE I.D. | WALL THICKNESS |
|---|---|---|---|---|
| 1/2 | 0.85 | 0.84 | 0.622 | 0.109 |
| 1.72 | 0.252 | 0.294 | ||
| 1.31 | 0.464 | 0.188 | ||
| 1.09 | 0.546 | 0.147 | ||
| 3/4 | 1.13 | 1.05 | 0.824 | 0.113 |
| 2.44 | 0.434 | 0.308 | ||
| 1.95 | 0.612 | 0.219 | ||
| 1.48 | 0.742 | 0.154 | ||
| 1 | 1.68 | 1.315 | 1.049 | 0.133 |
| 3.66 | 0.599 | 0.358 | ||
| 2.85 | 0.815 | 0.250 | ||
| 2.17 | 0.957 | 0.179 | ||
| 1 1/4 | 2.27 | 1.66 | 1.380 | 0.140 |
| 5.22 | 0.896 | 0.382 | ||
| 3.77 | 1.160 | 0.250 | ||
| 3.00 | 1.278 | 0.191 | ||
| 1 1/2 | 2.72 | 1.90 | 1.610 | 0.145 |
| 6.41 | 1.100 | 0.400 | ||
| 4.86 | 1.338 | 0.281 | ||
| 3.63 | 1.500 | 0.200 | ||
| 2 | 2.64 | 2.375 | 2.157 | 0.109 |
| 9.04 | 1.503 | 0.436 | ||
| 3.66 | 2.067 | 0.154 | ||
| 7.47 | 1.687 | 0.344 | ||
| 5.03 | 1.939 | 0.218 | ||
| 6.29 | 1.813 | 0.281 | ||
| 5.68 | 1.875 | 0.250 | ||
| 2 1/2 | 3.53 | 2.875 | 2.635 | 0.120 |
| 10.02 | 2.125 | 0.375 | ||
| 13.71 | 1.771 | 0.552 | ||
| 5.80 | 2.469 | 0.203 | ||
| 6.14 | 2.443 | 0.216 | ||
| 7.67 | 2.323 | 0.276 | ||
| 7.02 | 2.375 | 0.250 | ||
| 3 | 4.34 | 3.50 | 3.260 | 0.120 |
| 18.6 | 2.300 | 0.600 | ||
| 5.58 | 3.188 | 0.156 | ||
| 7.58 | 3.068 | 0.216 | ||
| 10.26 | 2.900 | 0.300 | ||
| 14.34 | 2.624 | 0.438 | ||
| 6.12 | 3.156 | 0.172 | ||
| 8.69 | 3.000 | 0.250 | ||
| 9.67 | 2.938 | 0.281 | ||
| 6.66 | 3.124 | 0.188 | ||
| 3 1/2 | 4.98 | 4.0 | 3.760 | 0.120 |
| 9.12 | 3.548 | 0.226 | ||
| 10.02 | 3.500 | 0.250 | ||
| 11.17 | 3.438 | 0.281 | ||
| 12.52 | 3.364 | 0.318 | ||
| 22.87 | 2..728 | 0.636 | ||
| 4 | 5.62 | 4.5 | 4.260 | 0.120 |
| 19.02 | 3.624 | 0.438 | ||
| 13.97 | 3.876 | 0.312 | ||
| 7.24 | 4.188 | 0.156 | ||
| 12.67 | 3.938 | 0.281 | ||
| 11.36 | 4.000 | 0.250 | ||
| 27.57 | 3.152 | 0.674 | ||
| 15.00 | 3.826 | 0.337 | ||
| 8.67 | 4.124 | 0.188 | ||
| 22.53 | 3.438 | 0.531 | ||
| 9.32 | 4.094 | 0.203 | ||
| 10.80 | 4.026 | 0.237 | ||
| 10.02 | 4.062 | 0.219 | ||
| 5 | 10.80 | 5.563 | 5.187 | 0.188 |
| 38.59 | 4.063 | 0.750 | ||
| 12.51 | 5.125 | 0.219 | ||
| 17.51 | 4.939 | 0.312 | ||
| 32.99 | 4.313 | 0.625 | ||
| 27.06 | 4.563 | 0.500 | ||
| 14.63 | 5.047 | 0.258 | ||
| 19.19 | 4.875 | 0.344 | ||
| 15.87 | 5.001 | 0.281 | ||
| 20.80 | 4.813 | 0.375 |
P5 Chrome Moly Pipe Size Chart In Inch
| O.D. x Thick | O.D x Thick | O.D x Thick |
|---|---|---|
| 48.3 x 3.2mm | 101.6 x 3.6mm | 63.5 x 3.6mm |
| 57.0 x 3.6mm | 139.7 x 6.3mm | 76.2 x 3.6mm |
| 44.5 x 3.2mm | 88.9 x 3.6mm | 60.3 x 5.0mm |
| 38.1 x 3.2mm | 76.2 x 4.0mm | 57.0 x 4.9mm |
| 57.0 x 3.2mm | 139.7 x 5.0mm | 70.0 x 6.3mm |
| 38.1 x 4.0mm | 76.2 x 5.0mm | 57.0 x 6.3mm |
| 44.5 x 6.3mm | 88.9 x 4.0mm | 63.5 x 3.2mm |
| 51.0 x 3.6mm | 114.3 x 5.0mm | 70.0 x 3.2mm |
| 48.3 x 3.6mm | 101.6 x 4.5mm | 63.5 x 4.0mm |
| 38.1 x 6.3mm | 76.2 x 6.3mm | 57.0 x 7.9mm |
| 51.0 x 3.2mm | 114.3 x 3.6mm | 63.5 x 7.9mm |
| 42.4 x 3.2mm | 82.5 x 4.5mm | 60.3 x 3.2mm |
| 51.0 x 6.3mm | 139.7 x 4.0mm | 70.0 x 3.6mm |
| 42.4 x 4.0mm | 88.9 x 3.2mm | 60.3 x 3.6mm |
| 50.8 x 4.5mm | 101.6 x 6.3mm | 63.5 x 6.3mm |
Tolerance Chart Of SA 335 Grade P5 Alloy Steel Seamless Pipes
| ASTM A450 | HOT ROLLED | Outside Diameter, mm | Tolerance, mm |
|---|---|---|---|
| 190.5＜OD≤228.6 | +0.4/-1.6 | ||
| 101.6＜OD≤190.5 | +0.4/-1.2 | ||
| OD≤101.6 | +0.4/-0.8 | ||
| COLD DROWN | Outside Diameter, mm | Tolerance, mm | |
| 190.5＜OD≤228.6 | +0.38/-1.14 | ||
| 25.4≤OD≤38.1 | ±0.15 | ||
| 76.2≤OD≤101.6 | ±0.38 | ||
| 50.8≤OD＜63.5 | ±0.25 | ||
| OD＜25.4 | ±0.10 | ||
| 63.5≤OD＜76.2 | ±0.30 | ||
| 101.6＜OD≤190.5 | +0.38/-0.64 | ||
| 38.1＜OD＜50.8 | ±0.20 | ||
| ASTM A530 & ASTM A335 | NPS | Outside Diameter, inch | Tolerance, mm |
| 4＜OD≤8 | +1.59/-0.79 | ||
| 8＜OD≤12 | +2.38/-0.79 | ||
| 1-1/2＜OD≤4 | ±0.79 | ||
| 1/8≤OD≤1-1/2 | ±0.40 | ||
| OD>12 | ±1% |
Testing and Inspection of SA335 P5 Round Pipe
Testing and Inspection
Dimension Chart of ASTM A335 Grade P5 Pipe
| NPS | WEIGHT (LB/FT) | OD (IN) | WT (IN) | ID (IN) |
|---|---|---|---|---|
| 12 | 53.52 | 12.75" | 0.406" | 11.938" |
| 24 | 171.30 | 24.000" | 0.688" | 22.624" |
| 1/8 | 0.24 | 0.405" | 0.068" | 0.269" |
| 16 | 82.77 | 16.000" | 0.500" | 15.000" |
| 5 | 14.62 | 5.563" | 0.258" | 5.047" |
| 1/4 | 0.42 | 0.540" | 0.088" | 0.364" |
| 8 | 28.55 | 8.625" | 0.322" | 7.981" |
| 3/8 | 0.57 | 0.675" | 0.091" | 0.493" |
| 18 | 104.70 | 18.000" | 0.562" | 16.876" |
| 1/2 | 0.85 | 0.840" | 0.109" | 0.622" |
| 3 | 7.58 | 3.500" | 0.216" | 3.068" |
| 20 | 123.10 | 20.000" | 0.594" | 18.812" |
| 1-1/4 | 2.27 | 1.660" | 0.140" | 1.380" |
| 6 | 18.97 | 6.625" | 0.280" | 6.065" |
| 10 | 40.48 | 10.750" | 0.365" | 10.020" |
| 3/4 | 1.13 | 1.050" | 0.113" | 0.824" |
| 1 | 1.68 | 1.315" | 0.133" | 1.049" |
| 4 | 10.79 | 4.500" | 0.237" | 4.026" |
| 2-1/2 | 5.79 | 2.875" | 0.203" | 2.469" |
| 14 | 63.50 | 14.000" | 0.438" | 13.124" |
| 3-1/2 | 9.11 | 4.000" | 0.226" | 3.548" |
| 1-1/2 | 2.72 | 1.900" | 0.145" | 1.610" |
| 2 | 3.65 | 2.375" | 0.154" | 2.067" |
A335 Grade P5 Cold Rolled Pipe Chemical Composition
SA335 P5 Seamless Pipe Mechanical Properties
ASTM A335 P5 Pipe Manufacturer in China Provides Pipes of the Highest Caliber With Exceptional Mechanical Properties.
Elongation
≥30
Yield Strength
≥205
Tensile Strength, MPa
≥415
Equivalent Chart Of P5 Alloy Steel Pipes
UNS
K41245
ASME
SA335 P5
ASTM
A335 P5
BS
3604 P1 625
ABS
ABS 14
ISO
2604 III TS37
Hardness Of SA335 P5 Round Pipe
| HARDNESS | ≤ 163HB |
|---|
Difference Between ASTM A335 P5 Pipe and ASTM A335 P9
ASTM A335 P5 Pipe VS ASTM A335 P9
| ASTM A335 P5 | ASTM A335 P9 | |
|---|---|---|
| Applications | Used in refineries | Used in refineries and is also highly resistant to corrosion and oxidation |
| Chemical composition | Contains 4–6% chromium and 0.45–0.65% molybdenum | Contains 8–10% chromium, 0.25–1% silicon, and 0.90–1.10% molybdenum |
| Uses | Refineries | Refineries, power plants, petrochemical plants, oil and gas equipment |
