Titanium Pipe Manufacturer in China

Home|Titanium Pipe

Affordable Supplier of Ti Exhaust Pipe in China, At Lowest Possible Price

titanium pipe

Exporter of ASTM B861 Gr2 Titanium Pipe in Wenzhou & 3 and 4 Inch Titanium Seamless Pipe in Various Grades, Refer Specification

Titanium Pipe Specification

Pipe Testing

TI Hollow Testing

  • Mechanical
  • PMI
  • Chemical
  • Ultrasonic
Standards

Pure Titanium Welded Pipe Standards

  • ASME SB 861 | ASTM B861
  • UNS : R56400 | R50400
  • UNS, DIN, API
pipe size icon

Ti Grade 5 Alloy Seamless Pipe Sizes

  • 4 – 219mm
  • OD: 4 to 219 mm
  • WT:0.5 to 20mm
welded pipe size icon

Titanium Gr2 Welded Pipe Sizes

  • OD: 5.0 to 1219.2 mm
  • WT: 0.5 to 20mm
  • 5.0 – 1219.2 mmh
Applications

Titanium Welded Pipe Applications

  • Specialty Chemicals
  • Chemical Equipment
  • Gas Processing
  • Off-Shore Oil Drilling Companies
  • Petrochemicals
Documentation

3 Titanium Exhaust Pipe Documentation

  • PMI Test Reports
  • Visual Inspection
  • Mill Test Certificates
Measurement

Measurement of ASTM B 338 Titanium Cold pipes

  • Outer diameter
  • Thickness, Length
Disadvantages

Titanium Alloy Pipes Disadvantages

  • Difficulty in Fabrication
  • Cost
  • Susceptibility to Contamination
  • Limited Availability of Grades
Origins

Titanium Pipe Grade 2 Origins

  • European
  • Russia
  • China
  • American
pipe Types

Types of Titanium Pipe

  • Rectangle
  • Hex
  • Round
  • Square
Packaging

ASME SB 861 ERW Pipe Packaging

  • Wooden Box
  • Bubble Wraps
  • Bundled
Advantages

ASTM B 338 Titanium Pipes Advantages

  • corrosion resistance
  • superior trength to weight ratio
  • Very high heat tolerance
  • Low Thermal Expansion
End Types

ASTM B 338 Titanium Cold Drawn pipe End Types

  • Plain end
  • Beveled
Features

Features of Ti Pipe

  • High strength
  • Thermal resistance
  • Excellent finish
  • Chemical resistance
pipe manufacturing process

Titanium 3 Inch Pipe Manufacturing Process

  • Precision Rolled
  • Hot Formed
  • Cold Formed
Pipe Surface Finish

Titanium Seamless Pipe Finish

  • Bright
  • Polished
  • Annealing

Types of Ti Alloy Pipe


Titanium Pipe Supplier in China Provides a Wide Variety of Commonly Used Pipe Types.


Titanium Seamless Pipe

Titanium Seamless Pipe

ASTM B861 Grade 2 ERW Pipe

ASTM B861 Grade 2 ERW Pipe

Titanium Round Pipe

Titanium Round Pipe

ASME SB 338 Square Pipe

ASME SB 338 Square Pipe

Titanium Alloy Rectangular Pipe

Titanium Alloy Rectangular Pipe

Titanium Pipe Exhaust Round Pipe

Titanium Pipe Exhaust Round Pipe

titanium erw pipe

Titanium erw pipe

B338 Gr 2 Polished Pipe

B338 Gr 2 Polished Pipe

Hot Rolled Titanium Grade 5

Hot Rolled Titanium Grade 5


Titanium Pipe Size Chart

Titanium Pipe Manufacturer in China Offers a Wide Range of Size

Titanium Pipe Size Chart

D/t Ratio Ave. Wall inches OD inches ID inches
9.04 0.083 0.750 0.584
31.25 0.020 0.625 0.585
12.05 0.083 1.000 0.834
14.93 0.134 2.000 1.732
15.79 0.095 1.500 1.310
12.50 0.020 0.250 0.210
25.00 0.020 0.500 0.460
13.39 0.028 0.375 0.319
14.29 0.035 0.500 0.430
18.75 0.020 0.375 0.335
14.58 0.120 1.750 1.510
17.86 0.049 0.875 0.777
42.86 0.035 1.500 1.430
35.71 0.028 1.000 0.944
57.14 0.035 2.000 1.930
12.76 0.049 0.625 0.527
26.79 0.028 0.750 0.694
15.06 0.083 1.250 1.084
43.75 0.020 0.875 0.835
50.00 0.035 1.750 1.680
7.14 0.035 0.250 0.180
9.62 0.065 0.625 0.495

Weight Chart of Titanium Alloy Pipe

DIMENSIONS WEIGHT PER WALL DIMENSIONS WEIGHT PER WALL
(MM) METRE (KG) (MM) (MM) METRE (KG) (MM)
40 x40 1.49 1.20 12.7 x 12.7 0.44 1.20
50 x50 3.08 2.00 20 x 20 0.88 1.50
40 x40 3.75 3.00 15 x 15 0.65 1.50
100 x 100 9.53 3.00 30 x 30 1.84 2.00
40 x40 1.85 1.50 12.7 x 12.7 0.55 1.50
50 x50 4.65 3.00 20 x 20 1.19 2.00
40 x40 2.45 2.00 15 x 15 0.53 1.20
100 x 100 6.40 2.00 30 x 30 1.37 1.50
50 x50 2.32 1.50 20 x 20 0.71 1.20
80 x80 7.53 3.00 30 x 30 1.10 1.20
70 x70 6.53 3.00 25 x 25 1.49 2.00

ASTM B861 Gr2 ERW Pipe Schedule Chart in Mm

NPS (Inches) Schedule 40 Schedule 5 Schedule 80 Schedule 10 Schedule 160
1 0.280" 0.095" 0.350" 0.120" 0.450"
1/2 0.200" 0.080" 0.250" 0.095" 0.350"
1-1/2 0.320" 0.120" 0.420" 0.150" 0.550"
1/8 0.140" 0.050" 0.180" 0.068" 0.240"
1-1/4 0.300" 0.105" 0.400" 0.140" 0.500"
1/4 0.180" 0.065" 0.220" 0.083" 0.300"
3/4 0.250" 0.090" 0.300" 0.105" 0.400"
2-1/2 0.400" 0.160" 0.500" 0.200" 0.750"
2 0.375" 0.140" 0.475" 0.170" 0.625"
10 0.850" 0.270" 1.050" 0.350" 1.500"
8 0.750" 0.250" 1.000" 0.320" 1.400"
12 1.000" 0.300" 1.250" 0.400" 1.750"
4 0.500" 0.200" 0.600" 0.250" 1.000"
3 0.450" 0.180" 0.550" 0.220" 0.800"
6 0.600" 0.220" 0.750" 0.280" 1.200"
5 0.550" 0.210" 0.700" 0.270" 1.100"


Applications Of Titanium Welded Pipe

Applications Of Titanium Welded Pipe

Applications

  • Gas Processing
  • Pulp and Paper Industry
  • Pharmaceuticals
  • Condensers
  • Sea Water Equipment
  • Heat Exchangers
  • Power Generation
  • Petrochemicals




Pressure Rating Chart of ASME SB 861 Hot Finished Pipe

Tube O.D.
(in.)		 Wall Thickness of Tube (inches)
Working Pressure (psig)
.120 .083 .035 .109 .028 .065 .095 .049
1/2     2300     4400   3200
1/4     4800   3700 9500   7000
3/4   4000       3000 4600 2200
5/16     3700     7300   5400
1/8     10100   7900
1 4300 2900   3900   2200 3400
3/8     3100     6100   4400

Titanium exhaust pipe Tolerance Chart

Tolerance OD, mm (in.) ±0.102 (0.004) ±0.127 (0.005)
Size OD, mm (in.) < 25.4 (< 3/8) 25.4-38.1 (1-1 1/2)
wt min wall % +20/-0 +20/-0

Ti Alloy Rectangular Pipe Chemical Composition

Grade O Al V N Ti Fe C H
Titanium Grade 2 0.25 max     0.03 max 99.2 min 0.3 max 0.1 max 0.015 max
Titanium Grade 5 0.20 max 5.5-6.75 max 3.5- 0.05 max 90 min 0.40 max 0.10 max 0.015 max

ASME SB 861 Seamless Pipe Equivalent Chart

STANDARD WERKSTOFF NR. UNS
Titanium Gr 2 3.7035 R50400
Titanium Gr 5 3.7165 R56400

ASTM B338 Titanium Welded Pipe Mechanical Properties

Standards Tensile Strength Elongation Yield Strength Melting Point
TI GR 2 Psi 49900 , MPa 344 20 % Psi 39900 , MPa 275 1665 °C (3030 °F)
Ti Gr 5 Psi 138000 , MPa 950 14 % Psi 128000 , MPa 880 1632 °C (2970 °F)

Titanium Exhaust Pipe Pipe Hs Code

Product HS Code
Titanium Pipe 81089090

Key Points of Titanium Pipe

  • Corrosion Resistance
  • Low Thermal Expansion
  • High Strength-to-Weight Ratio
  • High Temperature Resistance:


How does Yaye Industrial handle pipe shipment and logistics?

  • Warehousing
  • Customs Clearance
  • Supply Chain Management
