Nickel Alloy Pipe Supplier in China

Home|Nickel Alloy Pipe

Top Grade Manufacturer of Nickel 200 Seamless Pipe in China, With Various Grades

Ni Alloy Pipe Supplier in China

Exporter Of Alloy 201 Welded Tube & High Nickel Welded Pipe With Quick delivery, Check Specification & Schedule chart.

Nickel Alloy Pipe Specification

pipe size icon

Pure Nickel Seamless Pipe Sizes

  • WT:0.5 – 30mm
  • OD: 3-600mm
  • Length:0.5-12 meter
welded pipe size icon

SNi Welded Pipe Sizes

  • WT: 0.35 – 6.00mm
  • OD: 6-200mm
  • Length: 0.5-12 meter
End Types

Super Nickel Alloy Square Pipe End Types

  • Cut groove, Threaded
  • Plain end, Roll groove
  • Coupled, Bevel end
Features

Features of Super Nickel Alloy Round Pipe

  • Excellent Corrosion Resistance
  • Non-Magnetic Properties
  • Excellent Electrical Conductivity
pipe manufacturing process

Pure Nickel Alloy Pipes Manufacturing Process

  • Precision Rolled
  • Cold Formed
  • Hot formed
  • Cold drawn
Pipe Surface Finish

Nickel Clad Pipe Surface Finish

  • Mirror
  • Bright
  • Polished
  • Pickled
  • Annealing
Packaging

Nickel Thick Walled Pipe Packaging

  • Bundled
  • Bubble Wraps
  • Wooden Box
Advantages

Pure Nickel Seamless Pipe Advantages

  • Strong to High Pressure
  • Good Formality
  • Durable to High Temperature
Pipe Testing

Super Nickel Alloy Round Pipe Testing

  • Ultrasonic
  • Chemical
  • Mechanical
Standards

Pure Nickel Bright Annealed Pipe Standards

  • DIN, API, EN, UNS
  • GB, SUS, AISI,ASME
  • ASTM A312 | ASME SA 312
Origins

High Nickel Alloy Annealed Pipe Origins

  • American
  • Janpanese
  • Russia, India
  • China
pipe Types

Types of High Nickel Alloy Cold Drawn Pipe

  • Welded
  • Seamless
  • Electric Resistance Welded (ERW)
  • Fabricated
Measurement

Measurement of Pure Nickel Alloy Pipes

  • Thickness, Length
  • Inner diameter
  • Straightness, Ovality
  • Outer diameter
Disadvantages

Pure Nickel Seamless Pipe Disadvantages

  • Heavy
  • Expensive
  • Stress corrosion cracking
  • Machining
Applications

Supply Nickel Cold Finished Pipe Applications

  • Defence Industry
  • Food Processing Industry
  • Construction industry
  • Fabrication Industry
Documentation

Nickel Alloy Exhaust Pipe Documentation

  • Copy of Invoice
  • NABL Approved Lab Reports
  • Raw Material Test Reports
  • Bill of Lading.

Types of Super Nickel Alloy Round Pipe


Nickel Alloy Pipe Supplier in China Offers a Large Range of Commonly Used Pipe Types.


Nickel Thick Walled Pipe

Nickel Thick Walled Pipe

High Nickel Alloy Annealed Pipe

High Nickel Alloy Annealed Pipe

Nickel Clad Pipe

Nickel Clad Pipe

Ni Welded Pipe

Ni Welded Pipe

Pure Nickel Alloy Pipes

Pure Nickel Alloy Pipes

Nickel Alloy Pipe

Nickel Alloy Pipe

High Nickel Welded Pipe

High Nickel Welded Pipe

Pure Nickel Seamless Pipe

Pure Nickel Seamless Pipe

Nickel Alloy Exhaust Pipe

Nickel Alloy Exhaust Pipe


Pure Nickel Alloy Pipes Size Chart

Ni alloy pipe OD (mm) kg-meter In Pipe WT(mm) SCH
219.08 112.97 8 23.012 160
26.67 1.30 3/4 2.11 10S
114.30 22.67 4 8.56 80S
26.67 1.71 3/4 2.87 40S
60.33 11.29 2 8.742 160
26.67 2.23 3/4 3.91 80S
33.40 2.13 1 2.77 10S
60.33 7.60 2 5.54 80S
33.40 2.54 1 3.38 40S
60.33 5.52 2 3.91 40S
33.40 3.29 1 4.55 80S
60.33 3.99 2 2.77 10S
33.40 4.30 1 6.352 160
168.28 54.75 6 14.27 120
42.16 2.73 1¼ 2.77 10S
73.03 5.35 2½ 3.05 10S
48.26 5.49 1½ 5.08 80S
73.03 8.77 2½ 5.16 40S
42.16 3.44 1¼ 3.56 40S
114.30 8.50 4 3.05 10S
48.26 4.11 1½ 3.68 40S
114.30 16.32 4 6.02 40S
42.16 4.53 1¼ 4.85 80S
168.28 28.69 6 7.11 40S
48.26 3.16 1½ 2.77 10S
101.60 7.53 3½ 3.05 10S
42.16 5.69 1¼ 6.352 160
73.03 11.59 2½ 7.01 80S
101.60 18.92 3½ 8.08 80S
88.90 6.56 3 3.05 10S
13.72 0.50 1/4 1.65 10S
114.30 34.05 4 13.492 160
13.72 0.64 1/4 2.24 40S
88.90 21.67 3 11.132 160
13.72 0.81 1/4 3.02 80S
168.28 14.04 6 3.4 10S
17.15 0.64 3/8 1.65 10S
219.08 91.30 8 18.23 120
101.60 13.78 3½ 5.74 40S
17.15 0.86 3/8 2.31 40S
88.90 11.47 3 5.49 40S
219.08 43.20 8 8.18 40S
168.28 68.59 6 18.262 160
219.08 65.63 8 12.7 80S
88.90 15.51 3 7.62 80S
17.15 1.12 3/8 3.20 80S
141.30 31.44 5 9.53 80S
21.34 1.02 1/2 2.11 10S
141.30 49.87 5 15.882 160
21.34 1.29 1/2 2.77 40S
141.30 22.10 5 6.55 40S
21.34 1.65 1/2 3.73 80S
168.28 43.21 6 10.97 80S

Weight Chart of Pure Nickel Seamless Pipe

N.P.S. O.D.   Wall Thk. WEIGHT WEIGHT
MM IN Sch. MM IN Lb/ft kg/Mtr
48″ 1219 48.000 STD 9.525 0.375 190.738 284.112
        11.125 0.438 222.487 331.404
        22.225 0.875 440.383 655.969
        19.050 0.750 378.473 563.750
      XHY 12.700 0.500 253.650 377.822
1/2″ 21 0.840 40 STD 2.769 0.109 0.851 1.268
      80 STD 3.734 0.147 1.088 1.621
18″ 457 18.000   5.563 0.219 41.588 61.948
      STD 9.525 0.375 70.588 105.144
        15.875 0.625 115.978 172.754
        6.350 0.250 47.393 70.593
      40 14.275 0.562 104.666 155.904
      XHY 12.700 0.500 93.450 139.198
        7.137 0.281 53.176 79.208
      30 11.125 0.438 82.152 122.369
      20 7.925 0.312 58.939 87.792
3/4″ 27 1.050 40 STD 2.870 0.113 1.131 1.684
      80 STD 3.912 0.154 1.474 2.195
16” 406 16.000   4.775 0.188 21.748 47.290
      20 7.925 0.312 52.275 77.866


40

XHY

 12.700 0.500 82.770 123.289
        5.563 0.219 36.910 54.980


30

STD

 9.525 0.375 62.578 93.213
        11.125 0.438 72.797 108.433
      10 6.350 0.250 42.053 62.639
        8.738 0.344 57.519 85.677
        7.137 0.281 47.174 70.268
1″ 33 1.315 40 STD 3.378 0.133 1.679 2.501
      80 STD 4.547 0.179 2.172 3.325
42″ 1067 42.000   7.925 0.312 138.911 206.914
        19.050 0.750 330.413 492.163
      XHY 12.700 0.500 221.610 33.097
      STD 9.525 0.375 166.708 248.319
1 1/4″ 42 1.660 40 STD 3.556 0.140 2.273 3.385
      80 STD 4.851 0.191 2.997 4.464
30″ 762 30.000   6.350 0.250 79.433 118.318
        19.050 0.750 234.293 348.988
        7.137 0.281 89.189 132.851
        17.475 0.688 215.380 320.817
      10 7.925 0.312 98.925 147.353
      30 15.875 0.625 196.078 292.066
      20 XHY 12.700 0.500 157.530 234.647
      STD 9.525 0.375 118.648 176.731
        11.125 0.438 138.286 205.983
1 1/2″ 48 1.900 40 STD 3.683 0.145 2.718 4.048
      80 STD 5.080 0.200 3.361 5.409
36″ 914 36.000   6.350 0.250 95.453 142.180
        11.125 0.438 166.353 247.790
        7.137 0.281 107.196 159.672
        19.050

0.750

 282.353 420.576
      10 7.925 0.312 118.918 177.133
        17.475

0.688

 259.467 386.487
        15.875 0.625 236.128 351.723
      20 XHY 12.700 0.500 198.570 282.372
      STD 9.525 0.375 142.678 215.525
2″ 60 2.375 40 STD 3.912 0.154 3.653 5.441
      80 STD 5.537 0.218 5.022 7.480
24″ 610 24.000   6.350 0.250 63.413 94.456
        11.125 0.438 110.219 164.176
        19.050 0.750 186.233 277.401
        7.137 0.281 71.183 106.029
      40 17.475 0.688 171.293 255.148
        7.925 0.312 18.932 117.573
        15.875 0.625 156.028 232.410
      XHY 12.700 0.500 125.490 186.923
      20 STD 9.525 0.375 64.618 140.938
2 1/2″ 73 2.875 40 STD 5.516 0.203 5.793 8.629
      80 STD 7.010 0.276 7.661 11.411
20″ 508 20.000   6.350 0.250 52.733 78.547
        7.163 0.282 59.386 88.458
      20 STD 9.525 0.375 78.598 117.075
        17.475 0.688 141.901 211.368
        15.875 0.625 129.328 192.640
      40 15.088 0.594 123.110 183.378
      30 XHY 12.700 0.500 104.130 155.106
        11.125 0.438 91.508 136.305
        7.925 0.312 65.604 97.719
3″ 89 3.500 40 STD 5.486 0.216 7.576 11.284
      80 STD 7.620 0.300 10.253 15.272
14″ 356 14.000   4.775 0.188 27.732 41.308
        15.875 0.625 89.278 132.983
        7.137 0.281 41.172 61.327
        5.563 0.219 32.233 48.012
      XHY 12.700 0.500 72.090 107.381
      40 11.125 0.438 63.441 94.498
      STD 9.525 0.375 54.568 81.281
        7.925 0.312 45.611 67.939
      20 6.350 0.250 36.713 54.685
4″ 114 4.500   6.020 0.237 10.790 16.073
        8.560 0.337 14.983 22.318
12″ 324 12.750   4.775 0.188 25.222 37.570
        7.925 0.312 41.445 61.735
        14.275 0.562 73.154 108.966
        7.137 0.281 37.420 55.739
        5.563 0.219 29.309 43.657
        12.700 0.500 65.415 97.438
        10.312 0.406 53.525 79.727
        9.525 0.375 49.562 73.824
        6.350 0.250 33.375 49.713
6″ 168 6.625   4.775 0.188 12.924 19.252
      40 STD 7.112 0.280 18.974 58.263
        12.700 0.500 32.708 48.719
        5.516 0.203 13.923 20.739
      80 XHY 10.973 0.432 28.573 42.561
        5.563 0.219 14.983 22.318
        9.525 0.375 25.031 37.285
        6.350 0.250 17.021 25.354
        7.925 0.312 21.036 31.334
8″ 219 8.625   4.775 0.188 16.940 25.233
      80 XHY 12.700 0.500 43.388 64.627
        5.156 0.203 18.259 27.198
      60 10.312 0.406 35.638 53.085
        5.563 0.219 19.661 29.286
        9.525 0.375 33.041 49.216
      20 6.350 0.250 22.361 33.308
      40 8.179 0.322 28.554 42.352
      30 7.036 0.277 24.696 36.786
10″ 273 10.750   4.775 0.188 21.207 31.588
      80 15.088 0.594 64.429 95.969
        5.563 0.219 24.631 36.689
      60 XHY 12.700 0.500 54.735 81.530
      20 6.350 0.250 28.035 41.759
        11.125 0.438 48.238 71.852
      30 7.798 0.307 34.240 51.002
      40 STD 9.271 0.365 40.483 63.301
        8.738 0.344 38.231 56.946

Nickel Alloy Pipe Pressure Rating

Outside Dia of the Pipe(IN) Pipewall Thick (IN)
.120 .028 .109 .035 .095 .049 .083 .065
Working Pressure (psig)
1/2 2300 3200 4400
3/4 2200 3000 4000 4600
1/8 7900 10100
5/16 3700 5400 7300
1/4 3700 4800 7000 9500
1 2200 2900 3400 3900 4300
3/8 3100 4400 6100


Nickel Alloy Pipe Test

Nickel Alloy Pipe Test

Nickel Pipe Test

  • Mechanical Testing Such as Tensile of Area
  • Micro and MacroTest
  • Pitting Resistance Test
  • Positive Material Identification – PMI Testing
  • Hardness Test
  • Flattening Test
  • Chemical Analysis – Spectro Analysis
  • Flaring Test




Nickel Alloy Square Pipe Size Chart

Thick Range (IN.) Typical Value (IN.) GAUGE
0.060 - 0.065 0.065 16
0.175 - 0.185 0.18 7
0.025 - 0.029 0.028 22
0.157 - 0.167 0.165 8
0.031 - 0.035 0.035 20
0.140 - 0.150 0.148 9
0.075 - 0.085 0.083 14
0.038 - 0.042 0.042 19
0.126 - 0.136 0.134 10
0.087 - 0.097 0.095 13
0.044 - 0.049 0.049 18
0.066 - 0.074 0.072 15
0.112 - 0.122 0.12 11
0.053 - 0.058 0.058 17
0.101 - 0.111 0.109 12

HS Code Of Nickel Alloy Pipe

HS CODE DESCRIPTION
75072000 SEAMLESS NICKEL ALLOY PIPE

Chemical Composition Of Nickel Alloy Pipe

Nickel 201 Cr Fe Ni Cu Si C S Mo Mn P
– 0.40 max BALANCE 0.25 max 0.35 max 0.15 max 0.01 max – 0.35 max –
Nickel 200 Cr Fe Ni Cu Si C S Mo Mn P
– 0.4 max 99.0 Min 0.25 max 0.1 max 0.15 max 0.01 max – 0.35 max –

Nickel Steel Pipe Equivalent Chart

STANDARD GOST UNS EN BS WERKSTOFF NR. JIS AFNOR
Nickel 201 НП-2 N02201 LC-Ni 99 NA 12 2.4068 NW 2201 –
Nickel 200 НП-2 N02200 Ni 99.2 NA 11 2.4066 NW 2200 N-100M

Mechanical Properties Of Nickel Pipe

DENSITY ELONGATION MELTING POINT TENSILE STRENGTH YIELD STRENGTH (0.2%OFFSET)
8.9 G/Cm3 45 % 1446 °C (2635 °F) Psi – 67000 , MPa – 462 Psi – 21500 , MPa – 148

Difference Betweem Nickel Alloy Pipe and Stainless Steel pipe

Difference Nickel Alloy Pipe and Stainless Steel pipe
Nickel Alloy Pipe Stainless Steel pipe
generally performing better in highly corrosive environments more versatile and often used at room temperature
primarily composed of nickel with other alloying elements primarily iron with significant amounts of chromium and often some nickel.
used in chemical processing, marine applications, and high-temperature environments used in food processing, medical equipment, and general industrial applications.


What Makes Yaye Industrial Wenzhou Nickel Alloy Pipe Superior to Others in Terms of Efficiency ?

  • Exceptional Corrosion Resistance
  • High Strength at Elevated Temperatures
  • Excellent Resistance to Heat
  • Low Thermal Expansion Coefficient
