2 Piece Design Ball Valve Sizes
1/2 to 48"
3 Piece Design Ball Valve Standards
ASME B16.34
Types of Ball Valves
1 Piece Design Ball Valve Temperature
-20 to 450 °C
Metal Seated Ball Valve End Connection
3 Way Ball Valve Pressure Rating
Up to 10000Psi
Fire Safe Design Ball Valve Benefits
Trunnion-mounted Ball Valves Testing Methods
Brass Npt Ball Valve Disadvantages
Threads of Low Pressure Ball Valve
Cast Iron Ball Valve Dimension Chart
| DIMENSIONS: | 3/4 | ½ | 1 | 2 | 1 ½ | 3 | 2 ½ | 4 | 8 | 6 | 10 |
| A Face to Face | 4.625" | 4.25" | 5" | 7" | 6.5" | 8" | 7.5" | 9" | 11.5" | 10.5" | 13" |
| D Center of Valve to Handle End | 11.875" | 11.875" | 11.875" | 12.5" | 12.25" | 14" | 14" | 16" | 30.5" | 30.5" | 33.625" |
| B Center of Port to Top | 4.25" | 4.25" | 4.75" | 6.5" | 6" | 8.25" | 7.5" | 9" | 12.25" | 12" | 13.5" |
| E Port Diameter | 0.75" | 0.5" | 1" | 2" | 1.5" | 3" | 2.5" | 4" | 6" | 6" | 7.875" |
| C Flange Diameter | 3.875" | 3.5" | 4.25" | 6" | 5" | 7.5" | 7" | 9" | 13.5" | 11" | 16" |
| CV | 50 | 26 | 100 | 500 | 260 | 1245 | 750 | 2500 | 4150 | 5470 | 6700 |
| Weight lbs. | 7 | 6 | 10 | 24 | 17 | 50 | 43 | 77 | 190 | 149 | 309 |
| Bolt Holes | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | 8 | 8 | 12 |
Actuated Ball Valves Torque Chart
| Size | Torque (ft. lbs) |
| 1" | 10 |
| 6" | 260 |
| 2 ½" | 48 |
| ½" | 10 |
| 2" | 35 |
| 10" | 535 |
| ¾" | 10 |
| 1 ½" | 20 |
| 3" | 62 |
| 4" | 130 |
| 8" | 360 |
2 Piece Design Ball Valve
Metal Seated Ball Valve
3 Piece Design Ball Valve
1 Piece Design Ball Valve
3 Way Ball Valve
Fire Safe Design Ball Valve
Trunnion-mounted Ball Valves
Lined ball valves
Brass Npt Ball Valve
Process Of Working For Fire Safe Design Ball Valve
Applications Of Trunnion-mounted Ball Valves
Advantages Of Buying Ball Valves From Yaye Internationals
