Forged Gate Valve Sizes
15 NB - 300 NB
Forged Globe Valve Features
Forged Steel Lift Check Valve Standards
ASME B16.10
ASME B16.34
Connection of API 602 Forged Steel Lift Check Valve
Types of Forged Valve
Forged Globe Valve Operation
Forged Check Valve Temperature
7°C to 280°C
Forged Ball Valve End Connection
Application of Forged valves
Forged Trunnion Type Mountain Ball Valve Pressure Rating
Class 150 to 2500
Forged Globe Valve
Forged Check Valve
Forged Ball Valve
API 602 Forged Steel Swing Check Valve
Forged Steel Lift Check Valve
Forged Steel Butterfly Valve
Forged Lug Type Butterfly Valve
API 602 Forged Steel 2 Piece Design Ball Valve
Forged Steel Trunnion Type Mountain Ball Valve
Class 150 Forged Gate Valve Dimension Chart
| Size | F / F | P | WH | H(C) | H(O) | WT (kg) |
|---|---|---|---|---|---|---|
| 20 mm | 92 | 13 | 86 | 133 | 158 | 1.9 |
| 15 mm | 87 | 9.5 | 86 | 130 | 152 | 1.6 |
| 25 mm | 106 | 18 | 116 | 155 | 189 | 3.1 |
| 40 mm | 127 | 29 | 150 | 200 | 239 | 6.4 |
| 32 mm | 127 | 24 | 150 | 200 | 239 | 6.3 |
| 50 mm | 142 | 37 | 150 | 235 | 288 | 9.8 |
Class 300 Forged Gate Valve Dimension Chart
| Size | FT | F / F | F | WT (kg) |
|---|---|---|---|---|
| 20 mm | 14 | 152 | 115 | 4.7 |
| 15 mm | 13 | 140 | 95 | 3.2 |
| 25 mm | 16 | 165 | 125 | 6.5 |
| 40 mm | 19 | 190 | 155 | 12.1 |
| 32 mm | 18 | 178 | 135 | 10.5 |
| 50 mm | 21 | 216 | 165 | 17.2 |
Class 400 Forged Gate Valve Dimension Chart
| Size | F | FT | F / F | WT (kg) |
|---|---|---|---|---|
| 20 mm | 115 | 16 | 190 | 5.1 |
| 15 mm | 95 | 14 | 165 | 3.6 |
| 25 mm | 125 | 18 | 216 | 7.3 |
| 40 mm | 155 | 22 | 241 | 13.7 |
| 32 mm | 135 | 21 | 229 | 11.5 |
| 55 mm | 165 | 25 | 292 | 20 |
Class 600 Forged Gate Valve Dimension Chart
| Size | P | F / F | H(C) | WH | H(O) | WT (kg) |
|---|---|---|---|---|---|---|
| 20 mm | 13 | 92 | 133 | 86 | 158 | 1.9 |
| 15 mm | 9.5 | 87 | 130 | 86 | 152 | 1.6 |
| 32 mm | 24 | 127 | 200 | 150 | 239 | 6.3 |
| 25 mm | 18 | 106 | 155 | 116 | 189 | 3.1 |
| 50 mm | 37 | 142 | 235 | 150 | 288 | 9.8 |
| 40 mm | 29 | 127 | 200 | 150 | 239 | 6.4 |
Class 800 Forged Gate Valve Dimension Chart
| Size | WH | F / F | H(O) | P | H(C) | WT (kg) |
|---|---|---|---|---|---|---|
| 20 mm | 86 | 92 | 158 | 13 | 133 | 1.9 |
| 15 mm | 86 | 87 | 152 | 9.5 | 130 | 1.6 |
| 32 mm | 150 | 127 | 239 | 24 | 200 | 6.3 |
| 25 mm | 116 | 106 | 189 | 18 | 155 | 3.1 |
| 50 mm | 150 | 142 | 288 | 37 | 235 | 9.8 |
| 40 mm | 150 | 127 | 239 | 29 | 200 | 6.4 |
What Are The Maintainance Requiremnet For Forged Lift Check Valve
Following Are The Steps Followed For Maintainance
Difference Between Forged Valves And Cast Valves
| Forged Valves | Cast Valves |
|---|---|
| Metal is heated until soft, then shaped using mechanical forces | Metal is melted and poured into a mold |
| Better Mechanical Properties | Porous & May Break |
| Better For High Pressure, High Temperature Application | Better For long Run |
| More Expensive Due to Strength | Less Expensive |
Explain The Manufacturing Process Of Forged Globe Valve
| ➤ After heating the metal, it is compressed, bent, and shaped. |
| ➤ Use a die forging machine to fit the forged ball valve design. |
| ➤ A die is used to help mold the metal into a certain shape. |
| ➤ Quality control is ensured by assembling, inspecting, and testing the valve. |
How To Choose the right Forged Butterfly Valve for an Application?
Following Points Sould Be considered:
How Does Yaye Industrial Make Sure Customers Are Happy For Forged Valves?
