Cupro Nickel 70/30 Pipe

Home|Cupro Nickel 70/30 Pipe

Trustworthy Supplier of Cu Ni 70 30 Tube in China, at a Competitive Price

Cupro Nickel 70/30 Pipe

Manufacturer of ASTM B122 UNS C71500 Pipes & Cupro Nickel 70/30 Seamless Pipe here in Square, Round or Rectangular Form

Copper Nickel 70/30 pipe Specification

Origins

Copper Nickel 70/30 tube Origins

  • American
  • Russia, Janpanese
  • China ,
pipe Types

Types of Cu-ni 70/30 Pipe

  • Round
  • Square
  • Rectangle
pipe size icon

Cupro nickel 70/30 Pipe Sizes

  • 1/2" to 6" in OD & NB
welded pipe size icon

UNS C71500 welded pipe Sizes

  • Size: 5.0 to 1219.2 mm
pipe manufacturing process

WNR 2.0882 seamless tube Manufacturing Process

  • Cold drawn , Precision Rolled
  • Hot formed , Cold Formed
Pipe Surface Finish

70/30 CU-NI welded tube Surface Finish

  • Annealing , Mirror
  • Bright, Annealing
  • Polished
Pipe Testing

Cu Ni 70 30 Tube Testing

  • Geometric accuracy
  • Ultrasonic gaging
  • Liquid penetrant examination
Standards

ASTM B122 UNS C71500 Pipe Standards

  • ASTM / ASME
Applications

Cupro Nickel 70/30 Seamless Pipe Applications

  • Heat Exchangers
  • Petrochemical Industry
  • Chemical Processing
  • Marine Piping Systems
Documentation

Copper Nickel 70/30 pipe Documentation

  • Country of origin certificate
  • Bill of Lading
  • Copy of Invoice
Packaging

Copper Nickel 70/30 Tube Packaging

  • Wooden Boxes ,Bundles (hexagonal)
  • Wooden Boxes,PE Fabric Bundles
  • Custom
Advantages

CU-NI 70/30 pipe Advantages

  • Exceptional Corrosion Resistance
  • Low Maintenance
  • Environmental Friendliness
Measurement

Measurement of Cupro Nickel 70/30 seamless tube

  • Outer diameter
  • Thickness, Length
Disadvantages

Cu Ni 70 30 Pipe Disadvantages

  • Risk of galvanic corrosion
  • High cost
  • Poor machinability
End Types

ASTM B122 UNS C71500 Pipes End Types

  • Plain end,Threaded
  • Bevel end
Features

Features of Cupro Nickel 70/30 Seamless Pipe

  • Formability
  • Corrosion Resistance
  • Weldability

Types of Copper Nickel 70/30 Pipe


Cupro Nickel 70/30 Pipe Supplier in China Provides a Wide Range of Regularly Used Pipe Types.


copper nickel 70/30 Seamless Pipe

copper nickel 70/30 Seamless Pipe

Copper Nickel 70/30 Welded Pipe

Copper Nickel 70/30 Welded Pipe

CU-NI 70/30 pipe

CU-NI 70/30 pipe

Cupro Nickel 70/30 ERW Pipe

Cupro Nickel 70/30 ERW Pipe

70/30 copper nickel Rectangular Pipe

70/30 copper nickel Rectangular Pipe

UNS C71500 Welded Round Pipe

UNS C71500 Welded Round Pipe

70/30 Copper Nickel Square Pipe

70/30 Copper Nickel Square Pipe

wnr 2.0882 EFW pipe

wnr 2.0882 EFW pipe

70/30 CU-NI welded tube

70/30 CU-NI welded tube


C71500 Copper Nickel Pipe Sizes

C71500 Copper Nickel Pipe Manufacturer in China offers a wide Variety of Diameters to Satisfy Customer Needs.

C71500 Copper Nickel Pipe Sizes

Outside diameter of pipe DIN86019
10 bar 14 bar
ØD Wall Theoretical Wall Theoretical
thickness weight thickness weight
nominal actual actual actual
inch ND mm mm Kg/m mm Kg/m
0.38 10 16 1 0.42 1 0.42
0.5 15 20 1 0.53 1 0.53
0.75 20 25 1.5 0.99 1.5 0.99
0.125 10 1 0.26 1 0.26
0.25 12 1 0.31 1 0.31
1 25 30 1.5 1.2 1.5 1.2
1.25 32 38 1.5 1.54 1.5 1.54
1.5 40 44.5 1.5 1.81 1.5 1.81
2.5 65 76.1 2 4.16 2 4.16
2 50 57 1.5 2.34 1.5 2.34
3 80 88.9 2 4.88 2.5 6.07
4 100 108 2.5 7.41 2.5 7.41
5 125 133 2.5 9.16 3 10.95
6 150 159 2.5 10.99 3 13.14
7 175 193.7 2.5 13.43 3.5 18.7
8 200 219.1 3 18.21 3.5 21.19
10 250 267 3 22.24 4 29.55
12 300 323.9 4 35.94 5 44.78
14 350 368 4 40.89 5.5 56
16 400 419.1 4 46.62 6 69.6
18 450 457.2 4 50.91 6 76.03
20 500 508 4.5 63.63 6.5 91.55
24 600 610 5 84.96 8 135.26
28 700 711 6 118.8 9 177.45
32 800 813 6 135.99 10 225.53
36 900 914 8 203.57 11 278.98

Weight Chart of C71500 Copper Nickel Pipe

Size WT (in) OD (in) Weight
inch lbs/ft
1/4 OD 0.049 0.25 –
3/8 OD 0.035 0.38 0.15
1/4 OD 0.25 –
1/2 OD 0.5 0.22
12 0.25 12.75 42
14 14 41.86
16 16 52
18 18 59
20 20
24 24 77.6
3/4 OD 0.06 0.75 –
1/4 0.065 0.54 0.41
3/8 0.68 0.52
1/2 0.84 0.67
3/4 1.05 0.85
1 1.32 1.08
1-1/4 0.072 1.66 1.52
1-1/2 1.9 1.76
2 0.083 2.38 2.54
2-1/2 2.88 3.1
3 0.095 3.5 4.32
3-1/2 4 4.96
5/8 OD 0.049 0.62 –
3/4 OD 0.75 –
4 0.109 4.5 6.39
5 0.125 5.56 9.08
6 0.134 6.62 11.63
8 0.148 8.62 16.78
10 0.187 10.75 24.1

Copper nickel 70/30 Pipe Pressure Rating Chart

Properties Value
16 bar/ 232 psi -29°C/-20°F up to +75°C/+167°F
20 bar/ 290 psi -29°C/-20°F up to +38°C/+100°F

Applications Of Cu-ni 70/30 pipe

Applications Of Cu-ni 70/30 pipe

Applications

  • Chemical Equipment
  • Power Generation
  • Petrochemicals
  • Specialty Chemicals
  • Gas Processing




Chemical Composition of UNS C71500 seamless pipe

Pb

0.500 Max

Ni

29.000 min - 33.000 max

Mn

1.000 max

Fe

0.400 min - 1.000max

Cu

65.000 min

Zn

1.000 max

WRN 2.0882 welded pipe Mechanical Properties

Yield Strength

Min 88 - Max 483 MPa

Tensile Strength

MPa 372-517

Elongation

45%



Equivalent Grades Of Copper Nickel 70/30 Pipe

UNS

C71500

WNR

2.0882

ASTM

B122

DIN

2.0882



Physical Properties of Cu Ni 70/30 Pipe

Cupro Nickel 70/30 Pipe Manufacturer in China Provides Best Quality Pipes With Superior Physical Qualities.


  Value
Modulus of Rigidity 8300 ksi
Specific Heat Capacity 0.09 Btu/ lb /°F at 68°F
Melting Point 2260 °F
Density 0.323 lb/cu in. at 68°F
Specific Gravity 8.94
Electrical Conductivity 4.6 % IACS at 68°F
Thermal Conductivity 17 Btu/ sq ft/ ft hr/ °F at 68°F

Cu-ni 70/30 Pipe HS Code

Grade Cupro Nickel 70/30 Pipe
HS Code 74122090

What Testing Methods Does Yaye Industrial use for Quality Control?

  • During Production Inspection
  • Pre-Production Inspection
  • Pre-Shipment Inspection
