SA 333 Gr 6 Seamless Pipe Supplier in China , Used in Low Temperature Services

Table of Content

ASTM A333 Grade 6 Pipe Specification
Types of SA 333 Gr 6 Seamless Pipe
Weight Chart of A333 Grade 6 Carbon Steel Pipe
Pressure Class Of Carbon Steel A333 Grade 6 Pipe
A333 Grade 6 Square Pipe Tolerance Chart
Wall Thickness Of SA 333 Gr 6 Seamless Pipe
Types of A333 Pipe Coating
Chemical Composition Of ASTM A333 Grade 6 carbon Steel Cold Drawn Pipe
A333 Grade 6 Annealed Pipe Mechanical Properties
Equivalent Chart Of ASME SA 333 grade 6 Pipe
Difference Between ASTM A333 Grade 6 Pipe Vs ASTM A252 Grade 3 Pipe
Does Yaye Industrial Wenzhou Provide Any Astm A333 Grade 6 Pipe Coatings for Enhanced Protection ?

Get ASTM A333 Grade 6 Welded Pipe & A333 Grade 6 Carbon Steel Pipe With ASTM A333 Standard, Refer Specification & Weight Chart.

ASTM A333 Grade 6 Pipe Specification

ASTM A333 Grade 6 Pipe Sizes

Size – 1/2” NB to 48” NB
Wall Thickness: 3-12 Mm
Length: 5-7 Meter

SA 333 Gr 6 Pipe and Tube Sizes

Tube: 1/2” to 6”
Pipe:1/2 to 36 ” NB
OD: 1/2” to 60”

ASME SA 333 grade 6 pipe Manufacturing Process

Cold Formed
Cold drawn/li>
Hot Formed

ASTM A333 Grade 6 Welded Pipe Surface Finish

FBE/ Epoxy
Polished
Varnished

Carbon Steel ASTM A333 ERW Pipe Origins

Saudi Arabia, India
Morocco
Indonesia

Types of A333 Grade 6 Carbon Steel Pipe

Seamless
CEW Pipes
Fabricated

Measurement of ASTM A333 Grade 6 Welded Pipe

Inner diameter
Straightness, Ovality
Outer diameter

ASTM A333 Grade 6 Pipe Disadvantages

Impact properties
Surface imperfections
Corrosion resistance

ASTM A333 Grade 6 Welded Pipe End Types

Cut groove, Threaded
Plain end, Roll groove
Coupled, Bevel end

Features of ASTM A333 Grade 6 Pipe

Preheating
Wall thickness
Strength
Composition

ASTM A333 Grade 6 Pipe Advantages

Strength and durability
Resistant to high pH levels
Reduced maintenance
Safety

Carbon Steel ASTM A333 ERW Pipe Testing

Ultrasonic
Mechanical
Chemical
PMI

ASTM A333 Grade 6 carbon Steel Cold Drawn Pipe Packaging

Bundled
Wooden Box
Bubble Wraps

ASTM A333 Grade 6 Welded Pipe Standards

ASTM A333, ASME SA 333

A333 Seamless Pipe Applications

Chemical plants
Industrial plants
Refineries
Power plants

A333 Grade 6 Annealed Pipe Documentation

Visual Inspection
Mill Test Certificates
PMI Test Reports

Types of SA 333 Gr 6 Seamless Pipe

ASTM A333 Grade 6 Pipe Supplier in China Offers A Wide Range Of Frequently Used Pipes.

ASTM A333 Grade 6 Pipe

SA 333 Gr 6 Seamless Pipe

A333 Seamless Pipe

ASME SA 333 grade 6 pipe

Carbon Steel ASTM A333 ERW Pipe

A333 Grade 6 Annealed Pipe

ASTM A333 Grade 6 carbon Steel Cold Drawn Pipe

ASTM A333 Grade 6 Welded Pipe

A333 Grade 6 Carbon Steel Pipe

Weight Chart of A333 Grade 6 Carbon Steel Pipe

SIZE NPS	STANDARD TO XXHY	GALLON CAPACITY PER LINEAR FOOT	WALL THICKNESS	SECTION MODULUS	PIPE I.D.	SCHEDULE PIPE #	WEIGHT PER FOOT	PIPE O.D.
1/2	STD	.0158	0.109	.0407	0.622	40	0.85	0.84
	XXHY	.0026	0.294	.0577	0.252		1.72
		.0088	0.188	.0528	0.464	160	1.31
	XHY	.0122	0.147	.0478	0.546	80	1.09
6		1.6748	0.109	3.5769	6.407	5	7.59	6.625
		.7809	1.125	23.1237	4.375		66.14
		1.4688	0.312	9.3416	6.001		21.06
		1.6488	0.134	4.3475	6.357	10	9.30
		.8727	1.000	21.7719	4.625		60.13
		1.4391	0.344	10.111	5.937		23.10
		1.6260	0.156	5.0107	6.313		10.79
	XXHY	.9784	0.864	20.025	4.897		53.21
		1.5937	0.188	5.9351	6.249		12.94
		1.0977	0.719	17.8243	5.187	160	45.39
		1.5780	0.203	6.3804	6.219		13.94
		1.1787	0.625	16.1821	5.375		40.09
		1.2346	0.562	14.9806	5.501	120	36.43
		1.2909	0.500	13.711	5.625		32.74
		1.5620	0.219	6.8261	6.187		15.00
	XHY	1.3541	0.432	12.224	5.761	80	28.60
		1.5306	0.250	7.6905	6.125		17.04
	STD.	1.5008	0.280	8.4958	6.065	40	18.99
3/4	STD	.0277	0.113	.0705	0.824	40	1.13	1.05
	XXHY	.0077	0.308	.1103	0.434		2.44
		.0153	0.219	.1006	0.612	160	1.95
	XHY	.0225	0.154	.0853	0.742	80	1.48
1	STD	.0449	0.133	.1328	1.049	40	1.68	1.315
	XXHY	.0146	0.358	.2136	0.599		3.66
		.0271	0.250	.1904	0.815	160	2.85
	XHY	.0374	0.179	.1606	0.957	80	2.17
2		.1898	0.109	.4205	2.157	10	2.64	2.375
		.1344	0.281	.8666	1.813		6.29
	XXHY	.0922	0.436	1.1043	1.503		9.04
		.1434	0.250	.8045	1.875		5.68
	STD	.1743	0.154	.5606	2.067	40	3.66
		.1161	0.344	.9806	1.687	160	7.47
	XHY	.1534	0.218	.7309	1.939	80	5.03
1 1/4	STD	.0777	0.140	.2346	1.380	40	2.27	1.66
		.0328	0.382	.4110	0.896		5.22
		.0549	0.250	.3421	1.160	160	3.77
	XHY	.0666	0.191	.2913	1.278	80	3.00
1 1/2	STD	.1058	0.145	.3262	1.610	40	2.72	1.90
		.0494	0.400	.5977	1.100		6.41
		.0730	0.281	.5079	1.338	160	4.86
	XHY	.0918	0.200	.4118	1.500	80	3.63
2 1/2		.2833	0.120	.6870	2.635	10	3.53	2.875
	XXXHY	.1280	0.552	1.9971	1.771		13.71
	STD.	.2487	0.203	1.0640	2.469	40	5.80
		.1842	0.375	1.6371	2.125	160	10.02
		.2435	0.216	1.1169	2.443		6.14
	XHY	.2202	0.276	1.3386	2.323	80	7.67
		.2301	0.250	1.2468	2.375		7.02
3		.4336	0.120	1.0411	3.260		4.34	3.50
		.3672	0.250	1.9372	3.000		8.69
	XXHY	.2158	0.600	3.4243	2.300		18.6
		.4147	0.156	1.3122	3.188		5.58
		.2811	0.438	2.8774	2.624	160	14.34
		.4064	0.172	1.4265	3.156		6.12
	XHY	.3431	0.300	2.2253	2.900	80	10.26
		.3984	0.188	1.5342	3.124		6.66
		.3521	0.281	2.1207	2.938		9.67
	STD.	.3840	0.216	1.7241	3.068	40	7.58
5		1.0979	0.188	4.1161	5.187		10.80	5.563
	XXHY	.6734	0.750	12.0954	4.063		38.59
		.99647	0.312	6.4074	4.939		17.51
		1.0716	0.219	4.7279	5.125		12.51
		.9696	0.344	6.9358	4.875		19.19
		.7590	0.625	10.7976	4.313	160	32.99
	STD.	1.0391	0.258	5.4500	5.047	40	14.63
		.8495	0.500	9.2534	4.563	120	27.06
	XHY	.9449	0.375	7.4300	4.813	80	20.80
		1.0204	0.281	5.8644	5.001		15.87
3 1/2		.5768	0.120	1.3776	3.760	10	4.98	4.0
	XXHY	.3085	0.636	4.8795	2..728		22.87
		.4821	0.281	2.8562	3.438		11.17
	STD.	.5136	0.226	2.3939	3.548	140	9.12
	XHY	.4617	0.318	3.1400	3.364	80	12.52
		.4998	0.250	2.6001	3.500		10.02
4		.7404	0.120	1.7612	4.260	10	5.62	4.5
	XXHY	.4054	0.674	6.7927	3.152		27.57
		.7156	0.156	2.2354	4.188		7.24
		.4822	0.531	5.8997	3.438	160	22.53
		.6326	0.281	3.7021	3.938	60	12.67
		.6942	0.188	2.6296	4.124		8.67
		.5361	0.438	5.1790	3.624	120	19.02
		.6838	0.203	2.8173	4.094		9.32
	XHY	.5972	0.337	4.2713	3.826	80	15.00
		.6725	0.219	3.0184	4.062		10.02
		.6126	0.312	4.0273	3.876		13.97
	STD.	.6613	0.237	3.2145	4.026	40	10.80
		.6528	0.250	3.3611	4.000		11.36
		1.4082	0.375	10.893	5.875		25.05

Pressure Class Of Carbon Steel A333 Grade 6 Pipe

SIZE (IN)	SCHEDULE	OUTSIDE DIA(IN)	INSIDE DIA (IN)	WALL THICK (IN)	TEMP (oF)
					700	100	600	300	500	400	650	200
					ALLOWABLE STRESS (PSI)
					16800	23300	17300	20700	18900	20000	16900	21300
					ALLOWABLE STRESS (PSI)
1/2	401)	0.84	0.622	0.109	4865	6747	5010	5994	5473	5792	4894	6168
		0.84	0.252	0.294	16333	22653	16819	20125	18375	19444	16431	20708
	160	0.84	0.464	0.188	9160	12704	9433	11287	10305	10905	9215	11614
	802)	0.84	0.546	0.147	6837	9483	7041	8424	7692	8140	6878	8669
3/4	40	1.05	0.824	0.113	3957	5487	4074	4875	4451	4710	3980	5016
		1.05	0.434	0.308	12878	17861	13261	15868	14488	15331	12955	16328
	160	1.05	0.612	0.219	8412	11666	8662	10364	9463	10014	8462	10665
	80	1.05	0.742	0.154	5583	7743	5749	6879	6281	6647	5616	7079
1	40	1.315	1.049	0.133	3698	5128	3808	4556	4160	4402	3720	4688
		1.315	0.599	0.358	11694	16219	12042	14409	13156	13922	11764	14827
	160	1.315	0.815	0.25	7534	10448	7758	9283	8475	8969	7578	9552
	80	1.315	0.957	0.179	5133	7118	5285	6324	5774	6110	5163	6507
1 1/4	40	1.66	1.38	0.14	3039	4214	3129	3744	3419	3618	3057	3853
		1.66	0.896	0.382	9477	13143	9759	11677	10661	11282	9533	12015
	160	1.66	1.16	0.25	5753	7979	5925	7089	6473	6849	5788	7295
	80	1.66	1.278	0.191	4258	5905	4385	5246	4790	5069	4283	5398
1 1/2	40	1.9	1.61	0.145	2731	3788	2812	3365	3072	3251	2747	3462
		1.9	1.1	0.4	8506	11797	8759	10481	9570	10127	8557	10785
	160	1.9	1.338	0.281	5636	7817	5804	6944	6341	6710	5670	7146
	80	1.9	1.5	0.2	3862	5356	3977	4759	4345	4598	3885	4897
2	10	2.375	2.157	0.109	1601	2220	1648	1972	1801	1906	1610	2030
		2.375	1.503	0.436	7230	10027	7445	8908	8134	8607	7273	9167
	40	2.375	2.067	0.154	2298	3187	2366	2831	2585	2736	2312	2913
	160	2.375	1.687	0.344	5505	7634	5668	6782	6193	6553	5537	6979
	80	2.375	1.939	0.218	3329	4616	3428	4101	3745	3963	3348	4220
		2.375	1.813	0.281	4391	6090	4522	5410	4940	5227	4417	5567
		2.375	1.875	0.25	3862	5356	3977	4759	4345	4598	3885	4897
2 1/2	10	2.875	2.635	0.12	1451	2012	1494	1788	1632	1727	1460	1840
	40	2.875	2.469	0.203	2514	3487	2589	3098	2829	2993	2529	3188
		2.875	1.771	0.552	7622	10571	7849	9391	8575	9074	7667	9664
	80	2.875	2.323	0.276	3494	4846	3598	4305	3931	4159	3515	4430
		2.875	2.443	0.216	2686	3725	2766	3309	3022	3197	2702	3405
	160	2.875	2.125	0.375	4893	6786	5039	6029	5505	5825	4922	6204
		2.875	2.375	0.25	3140	4355	3234	3869	3533	3738	3159	3981
3		3.5	3.26	0.12	1184	1643	1502	1459	1333	1410	1192
		3.5	2.3	0.6	6675	9258	8464	8225	7510	7947	6715
		3.5	3.188	0.156	1553	2154	1969	1913	1747	1849	1562
		3.5	2.3	0.6	6675	9258	8464	8225	7510	7947	6715
		3.5	3.156	0.172	1719	2384	2179	2118	1934	2046	1729
	160	3.5	2.624	0.438	4673	6480	5924	5757	5257	5563	4700
		3.5	3.124	0.188	1886	2615	2391	2324	2122	2245	1897
	80	3.5	2.9	0.3	3092	4288	3920	3810	3479	3681	3110
	40	3.5	3.068	0.216	2181	3025	2766	2688	2454	2597	2194
		3.5	2.938	0.281	2883	3998	3655	3552	3243	3432	2900
		3.5	3	0.25	2545	3530	3227	3136	2864	3030	2561
3 1/2	10	4	3.76	0.12	1033	1432	1309	1273	1162	1230	1039
		4	2..728	0.636	6121	8489	7761	7542	6886	7287	6157
		4	3.438	0.281	2501	3469	3171	3082	2814	2977	2516
	140	4	3.548	0.226	1988	2758	2521	2450	2237	2367	2000
	80	4	3.364	0.318	2853	3956	3617	3515	3209	3396	2870
		4	3.5	0.25	2211	3066	2803	2724	2487	2632	2224
4	10	4.5	4.26	0.12	916	1270	1161	1128	1030	1090	921
		4.5	4.094	0.203	1572	2181	1994	1938	1769	1872	1582
	60	4.5	3.938	0.281	2208	3063	2800	2721	2485	2629	2222
		4.5	3.876	0.312	2466	3421	3127	3039	2775	2936	2481
		4.5	3.152	0.674	5718	7930	7249	7045	6432	6807	5752
	80	4.5	3.826	0.337	2677	3712	3394	3298	3011	3186	2693
	120	4.5	3.624	0.438	3547	4919	4497	4370	3990	4222	3568
		4.5	4.124	0.188	1452	2014	1841	1789	1634	1729	1461
		4.5	4.062	0.219	1701	2360	2157	2096	1914	2026	1712
		4.5	4.188	0.156	1198	1662	1519	1476	1348	1426	1205
	160	4.5	3.438	0.531	4378	6072	5551	5394	4925	5212	4404
5		5.563	5.187	0.188	1167	1619	1480	1438	1313	1389	1174
	40	4.5	4.026	0.237	1847	2562	2342	2276	2078	2199	1858
		4.5	4	0.25	1953	2709	2477	2407	2198	2326	1965
		5.563	4.063	0.75	5078	7042	6438	6256	5712	6045	5108
		5.563	4.939	0.312	1973	2736	2501	2431	2220	2349	1985
		5.563	5.125	0.219	1366	1894	1732	1683	1536	1626	1374
	160	5.563	4.313	0.625	4148	5753	5259	5111	4666	4938	4172
	40	5.563	5.047	0.258	1618	2244	2052	1994	1821	1927	1628
	120	5.563	4.563	0.5	3254	4513	4126	4009	3661	3874	3273
	80	5.563	4.813	0.375	2394	3320	3035	2950	2693	2850	2408
		5.563	5.001	0.281	1769	2453	2242	2179	1990	2106	1779
		5.563	4.875	0.344	2186	3032	2771	2693	2459	2602	2199

A333 Grade 6 Square Pipe Tolerance Chart

OUTSIDE DIA, IN	TOLERANCE, %
3≤OD≤18, WT/OD>5%	+15.0/-12.5
OD≥20, WT/OD>5%	+15.0/-12.5
1/8≤OD≤2-1/2	+20.0/-12.5
OD≥20, WT/OD≤5%	+22.5/-12.5
3≤OD≤18, WT/OD≤5%	+22.5/-12.5

Wall Thickness Of SA 333 Gr 6 Seamless Pipe

Outside Dia(IN)	NPS(IN)	ASTM A333 Grade 6 Carbon Steel Seamless Pipes Schedule
		SCH XXS	SCH 10	SCH 120	SCH 160	SCH STD	SCH 80	SCH 30	SCH XS	SCH 60	SCH 140	SCH 40	SCH 100	SCH 20
		Wall Thickness (in)
0.405	1/8					0.068	0.095		0.095			0.068
0.540	1/4					0.088	0.119		0.119			0.088
0.675	3/8					0.091	0.126		0.126			0.091
0.840	1/2	0.294			0.187	0.109	0.147		0.147			0.109
1.050	3/4	0.308			0.219	0.113	0.154		0.154			0.113
1.315	1	0.358			0.250	0.133	0.179		0.179			0.133
1.660	1 1/4	0.382			0.250	0.140	0.191		0.191			0.140
1.900	1 1/2	0.400			0.281	0.145	0.200		0.200			0.145
2.375	2	0.436			0.344	0.154	0.218		0.218			0.154
2.875	2 1/2	0.552			0.375	0.203	0.276		0.276			0.203
3.500	3	0.600			0.438	0.216	0.300		0.300			0.216
4.000	3 1/2					0.226	0.318		0.318			0.226
4.500	4	0.674		0.438	0.531	0.237	0.337		0.337			0.237
5.563	5	0.750		0.500	0.625	0.258	0.375		0.375			0.258
6.625	6	0.864		0.562	0.719	0.280	0.432		0.432			0.280
8.625	8	0.875		0.719	0.906	0.322	0.500	0.277	0.500	0.406	0.812	0.322	0.594	0.250
10.750	10	1.000		0.844	1.125	0.365	0.594	0.307	0.500	0.500	1.000	0.365	0.719	0.250
12.750	12	1.000		1.000	1.312	0.375	0.688	0.330	0.500	0.562	1.125	0.406	0.844	0.250
14.000	14		0.250	1.094	1.406	0.375	0.750	0.375	0.500	0.594	1.250	0.438	0.938	0.312
16.000	16		0.250	1.219	1.594	0.375	0.844	0.375	0.500	0.656	1.438	0.500	1.031	0.312
18.000	18		0.250	1.375	1.781	0.375	0.938	0.438	0.500	0.750	1.562	0.562	1.156	0.312
20.000	20		0.250	1.500	1.969	0.375	1.031	0.500	0.500	0.812	1.750	0.594	1.281	0.375
22.000	22		0.250	1.625	2.125	0.375	1.125	0.500	0.500	0.875	1.875		1.375	0.375
24.000	24		0.250	1.812	2.344	0.375	1.219	0.562	0.500	0.969	2.062	0.688	1.531	0.375
30.000	30		0.312			0.375		0.625	0.500					0.500
32.000	32		0.312			0.375		0.625				0.688		0.500
34.000	34		0.312			0.375		0.625				0.688		0.500
36.000	36		0.312			0.375		0.625				0.750		0.500
42.000	42					0.375		0.625				0.750		0.500

Types of A333 Pipe Coating

Types of A333 Pipe Coating

LPE Coating And Lining
FBE Coated
3LPE Coated
Epoxy Coated
Black Paint Coated

Anti-Corrosion Paint
3LPP Coated
Varnish Coated
Dual Layer FEB
Galvanizing Coated

Chemical Composition Of ASTM A333 Grade 6 carbon Steel Cold Drawn Pipe

	Ni	S(max)	C(max)	Ni	Mn	Si	P(max)
Grade 6		0.025	0.3		0.29 – 1.06	0.10 (min)	0.025
Grade 3	3.18 – 3.82	0.025	0.19	3.18 – 3.82	0.31 – 0.64	0.18 – 0.37	0.025
Grade 1		0.025	0.03		0.40 – 1.06		0.025

A333 Grade 6 Annealed Pipe Mechanical Properties

ASTM A333 Grade 6 Pipe Manufacturer in China Provides The Best Pipes With Exceptional Mechanical Properties.

Elongation

30 min

Yield Strength

35 000 (240)

Tensile Strength

60 000 (415)

Equivalent Chart Of ASME SA 333 grade 6 Pipe

ASTM

ASTM A333/p>

ASME

ASME SA 333

NFA

ASTM A333 Grade6

EN P215NL Grade 10216-4

NFA A 36-2051 Grade A 42 AP

DIN

DIN 17178

Difference Between ASTM A333 Grade 6 Pipe Vs ASTM A252 Grade 3 Pipe

Difference ASTM A333 Grade 6 Pipe Vs ASTM A252 Grade 3 Pipe

ASTM A333 Grade 6 Pipe Vs A333 Grade 6 Carbon Steel Pipe

	ASTM A333 Grade 6 Pipe	ASTM A252 Grade 3 Pipe
Strength	Lower tensile strength compared to A252 Grade 3 but with better low-temperature performance.	High tensile and yield strength, making it ideal for structural support.
Material properties	Medium carbon steel with specific chemical composition to maintain toughness at low temperatures.>	High-strength steel with a higher carbon content compared to A333 Grade 6, resulting in greater tensile strength.
Applications	Used in applications requiring resistance to low temperatures, like cryogenic systems or pipelines in cold climates.	Primarily used for piling applications in construction due to its high strength and ability to withstand heavy loads.

Does Yaye Industrial Wenzhou Provide Any Astm A333 Grade 6 Pipe Coatings for Enhanced Protection ?

ASTM A333 Grade 6 pipes can be coated with a variety of materials for extra protection, including:

3PE/3LPE
Epoxy
FBE
Galvanized
Varnished
CRA or stainless clad
