API 5L X52 Pipe

Home|API 5L X52 Pipe

Top - grade Supplier of X52 PSL2 Seamless Pipe in China, At Best Price

API 5L X52 Pipe

API 5L X52 Pipe Specification

pipe size icon

X52 Seamless Pipe Sizes

  • OD: 13.7 – 610 mm
  • Length:6 meters
  • Wall Thickness: 3.02 – 31.75mm
welded pipe size icon

API 5L X52 Welded Pipe Sizes

  • 2″ NPS - 24″
  • Length:up to 12 Meters
  • Wall Thickness: Sch 10-160
pipe manufacturing process

API 5L X52 Grade B LSAW Pipe Manufacturing Process

  • Cold Formed
  • Precision Rolled
  • Hot Formed
Pipe Surface Finish

X52 Grade PSL1 Line Pipe Surface Finish

  • Bright, Mirror
  • Polished
  • Annealing
Pipe Testing

API 5L Gr X52 HIC Pipeline Testing

  • Mechanical
  • Visual Inspection
  • Non Destructive
  • PMI Testing
Standards

X52 Steel Nace Pipe Standards

  • ASME B36.10M
  • ISO 3183 L360
  • API 5L X52
Applications

API 5L Grade X52 Epoxy Coated Pipe Applications

  • Oil & gas
  • Transportation
  • Offshore
  • Natural Gas
Documentation

Grade X52 Sour Service Pipe Documentation

  • EN 10204 3.1
  • Mill TC EN 10204 3.1
  • Third Party Inspection Reports
Origins

API 5L Grade X52 Carbon Steel Pipe Origins

  • American
  • Janpanese
  • Russia, India
  • China
pipe Types

Types of API 5L X52 Pipe

  • Hex
  • Round
  • Rectangle
  • Square
Packaging

X52 ERW Pipe Packaging

  • Bundled
  • Bubble Wraps
  • Wooden Box
Advantages

X52 PSL2 Seamless Pipe Advantages

  • High Strength
  • Good Cracking Resistance
  • Toughness
  • Impact Resistance
Measurement

Measurement of API 5L X52 Grade B LSAW Pipe

  • Straightness, Ovality
  • Outer diameter
  • Inner diameter
  • Thickness, Length
Disadvantages

X52 Grade PSL1 Line Pipe Pipe Disadvantages

  • High cost
  • Weld seam Issues
  • Corrosion possibility
  • Limited toughness
End Types

API 5L Gr X52 HIC Pipe End Types

  • Cut groove, Threaded
  • Coupled, Bevel end
  • Plain end, Roll groove
Features

Features of X52 Steel Nace Pipe

  • Versatile Application
  • Quality Assurance
  • Finishing
  • Surface Protection

Types of API 5L X52 Pipe


API 5l X52 Pipe Supplier in China Provides a Many Varieties of Generally Used Pipe Types.


API 5L X52 Grade B LSAW Pipe

API 5L X52 Grade B LSAW Pipe

X52 Grade PSL1 Line Pipe

X52 Grade PSL1 Line Pipe

API 5L Gr X52 HIC Pipe

API 5L Gr X52 HIC Pipe

X52 Steel Nace Pipe

X52 Steel Nace Pipe

API 5L Grade X52 Epoxy Coated Pipe

API 5L Grade X52 Epoxy Coated Pipe

Grade X52 Sour Service Pipe

Grade X52 Sour Service Pipe

API 5L Grade X52 Carbon Steel Pipe

API 5L Grade X52 Carbon Steel Pipe

X52 ERW Pipe

X52 ERW Pipe

X52 PSL2 Seamless Pipe

X52 PSL2 Seamless Pipe


API 5L Grade X52 Carbon Steel Pipe & X52 ERW Pipe With Superior Mechanical Strength, Check Dimension, Wall Thickness & Pressure Rating

Thickness Chart API 5L X52 Grade B LSAW Pipe

NPS  (in) Outside Diameter (in)
SCH 30 SCH 20 SCH 10 SCH STD SCH XS SCH 60 SCH 40 SCH 120 SCH 100 SCH 80 SCH XXS SCH 160 SCH 140
Wall Thickness (in)
3/4 1.050 0.113 0.154 0.113 0.154 0.308 0.219
2 1/2 2.875 0.203 0.276 0.203 0.276 0.552 0.375
1 1.315 0.133 0.179 0.133 0.179 0.358 0.250
1/4 0.540 0.088 0.119 0.088 0.119
3/8 0.675 0.091 0.126 0.091 0.126
34 34.000 0.312 0.500 0.312 0.375 0.688
1 1/2 1.900 0.145 0.200 0.145 0.200 0.400 0.281
36 36.000 0.312 0.500 0.312 0.375 0.750
1 1/4 1.660 0.140 0.191 0.140 0.191 0.382 0.250
2 2.375 0.154 0.218 0.154 0.218 0.436 0.344
3 3.500 0.216 0.300 0.216 0.300 0.600 0.438
1/8 0.405 0.068 0.095 0.068 0.095
1/2 0.840 0.109 0.147 0.109 0.147 0.294 0.187
5 5.563 0.258 0.375 0.258 0.500 0.375 0.750 0.625
3 1/2 4.000 0.226 0.318 0.226 0.318
4 4.500 0.237 0.337 0.237 0.438 0.337 0.674 0.531
32 32.000 0.312 0.500 0.312 0.375 0.688
8 8.625 0.250 0.322 0.500 0.406 0.322 0.719 0.594 0.500 0.875 0.906 0.812
10 10.750 0.250 0.365 0.500 0.500 0.365 0.844 0.719 0.594 1.000 1.125 1.000
6 6.625 0.280 0.432 0.280 0.562 0.432 0.864 0.719
12 12.750 0.250 0.375 0.500 0.562 0.406 1.000 0.844 0.688 1.000 1.312 1.125
18 18.000 0.250 0.312 0.250 0.375 0.500 0.750 0.562 1.375 1.156 0.938 1.781 1.562
22 22.000 0.250 0.375 0.250 0.375 0.500 0.875 1.625 1.375 1.125 2.125 1.875
14 14.000 0.250 0.312 0.250 0.375 0.500 0.594 0.438 1.094 0.938 0.750 1.406 1.250
20 20.000 0.250 0.375 0.250 0.375 0.500 0.812 0.594 1.500 1.281 1.031 1.969 1.750
16 16.000 0.250 0.312 0.250 0.375 0.500 0.656 0.500 1.219 1.031 0.844 1.594 1.438
24 24.000 0.250 0.375 0.250 0.375 0.500 0.969 0.688 1.812 1.531 1.219 2.344 2.062
30 30.000 0.312 0.500 0.312 0.375 0.500
42 42.000 0.500 0.375 0.750

Dimension Chart OF API 5L Grade X52 Welded Pipe

API 5L X52 Pipe Manufacturer in China offers a Various Dimension Of Pipe For Customer Applications.

NB DN OD (inches) Schedule
SCH 10 SCH 5 SCH 30 SCH 20 SCH 60 SCH 40 SCH 100 SCH 80 SCH 160 SCH 120
1" 25 1.315 0.11 0.065 0.114 x x 0.133 0.2 x 0.25 x
3/4" 20 1.05 0.11 0.065 0.095 x x 0.113 0.17 x 0.219 x
2.1/2" 65 2.875 0.12 0.083 x x x 0.203 0.3 x 0.375 x
2" 50 2.375 0.12 0.065 x x x 0.154 0.25 x 0.344 x
6" 150 6.625 0.13 0.109 x x x 0.28 0.562 x 0.719 x
4" 100 4.5 0.12 0.083 x x x 0.237 0.437 x 0.531 x
10" 250 10.75 0.17 0.134 0.307 0.25 0.5 0.365 0.843 0.718 1.125 1.0

X52 ERW Pipe Pipes Dimension Tolerances

 Pipes types Pipes Size (mm) Tolerances
Cold drawn OD 30～50 ±0.45
10～30 ±0.40mm
6～10 ±0.20mm
>50 ±1%
WT >1～3 + 15%, – 10%
<1 ±0.15mm
>3 + 12.5%, – 10%
Hot rolled OD ≥50 ±1%
<50 ±0.50mm
WT ≥4～20 +15%, -12.5%
<4 ±12.5%
>20 ±12.5%

API 5L Grade X52 Welded Pipe Pressure Rating Chart

Nominal Size (mm) Schedule no. Wall Thickness (mm) Temperature (°C)
-29 - 38 400 370 205 350 4301 260 450
137.8 89.6 115.7 137.8 117.1 74.4 130.2 59.9
15 XXS 7.47 98245 63857 82522 98245 83507 53053 92836 42739
XS 80 3.73 48092 31260 40396 48092 40878 25969 45466 20918
160 4.78 62830 40837 52777 62830 53404 33929 59378 27333
STD 40 2.77 34416 22372 28910 34416 29255 18589 32528 14972
250 120 21.44 20036 13022 16825 20036 17032 10817 18934 8716
30 7.8 7028 4568 5905 7028 5974 3796 6642 3059
  20 6.35 5698 3707 4789 5698 4844 3080 5388 2480
XS 60 12.7 11596 7538 9736 11596 9853 6263 10955 5043
80 15.09 13863 9012 11644 13863 11781 7483 13098 6028
100 18.26 16922 10996 14214 16922 14386 9136 15992 7359
STD 40 9.27 8385 5450 7048 8385 7131 4527 7923 3652
XXS 140 25.4 23998 15599 20153 23998 20394 12960 16474 10438
160 28.58 27229 17700 22875 27229 23143 14703 25734 11844
32 XXS 9.70 64601 41988 54266 64601 54906 34884 61045 28097
XS 80 4.85 30178 19616 25348 30178 25651 16295 28518 13125
160 6.35 40596 26389 34099 40596 34505 21924 38364 17659
25 XS 80 4.55 36283 23584 30474 36283 30862 19595 34285 15785
STD 40 3.38 26251 17060 22048 26251 22310 14173 24804 11417
160 6.35 52481 34112 44082 52481 44606 28339 49594 22827
XXS 9.09 77030 50070 64704 77030 65476 41595 72793 33506
20 XXS 7.82 83107 54024 69809 83107 70643 44881 78539 36152
XS 80 3.91 39418 25617 33106 39418 33506 21283 37247 17142
160 5.56 58152 37799 48843 58152 49429 31398 54955 25293
STD 40 2.87 28070 18245 23578 28070 23860 15158 26526 12209
65 XXS 14.02 53081 34498 44585 53081 45116 28662 50159 23088
XS 80 7.01 24818 16129 20849 24818 21097 13401 23447 10797
160 9.53 34615 22503 29076 34615 29420 18693 32714 15055
STD 40 5.16 17914 11644 15048 17914 15227 9674 16929 7793
80 STD 40 5.49 15558 10108 13063 15558 13222 8399 14969 6766
XS 80 7.62 21986 14290 18472 21968 18693 11871 20780 9563
160 11.13 33079 21497 27780 33079 28111 17859 31253 14386
XXS 15.24 46976 30536 39459 46976 39928 25369 44392 20436
40 XXS 10.16 58779 38205 49374 58799 49966 31742 55547 25569
XS 80 5.08 27402 17811 23019 27402 23295 14800 25900 11919
160 7.14 39738 25858 33416 39738 33816 21483 37599 17308
STD 40 3.68 19444 12636 16329 19444 16529 10550 18375 8454
150 XXS 160 18.26 28325 18410 23784 28325 24074 15296 26768 12319
XS 80 10.97 16474 10707 13842 16474 14007 8895 15571 7165
120 14.27 21745 14138 18265 21745 18448 11747 20553 9460
STD 40 7.11 10550 6828 8819 10550 8924 5370 9928 4568
100 XXS 17.12 40348 26230 33892 40348 34298 21786 38129 17549
XS 80 8.56 19058 12388 16012 19058 16198 12094 18010 8289
120 11.13 25190 16371 21159 25190 21407 13601 23805 10995
160 13.49 31019 20160 26058 31019 26368 16750 29310 13208
STD 40 6.02 13187 8571 11079 13187 11210 7124 12464 5739
200 STD 40 8.18 9246 6008 7765 9246 7855 4995 8737 4024
60 10.31 11741 7627 9860 11741 9977 6339 11093 5105
XS 80 12.70 14572 9474 12237 14572 12388 7868 13766 6338
140 20.62 24308 15799 20415 24308 20656 13125 22971 10569
120 18.26 21345 13876 17935 21345 18148 11527 20174 9288
100 15.09 17452 11341 14655 17452 14834 9426 16488 7593
XXS 22.23 26334 17115 22124 26334 22386 14221 24877 11458
160 23.01 27340 17769 22964 27340 23240 14765 25838 11892

Schedule Chart Of API 5L Grade X42 ERW Pipe

NB OD (mm) DN Pipe Schedule
SCH 40 SCH 30 SCH 5 SCH 100 SCH 80 SCH 10 SCH 60 SCH 120 SCH 160 SCH 20
12" 323.85 300 10.31 8.38 4.19 21.41 17.45 4.57 12.7 25.40 33.32 6.35
1" 33.40 25 3.38 2.90 1.65 x 4.55 2.77 x 5.08 6.35 x
2.1/2" 73.02 65 5.16 x 2.11 x 7.01 3.05 x 7.62 9.53 x
4" 114.3 100 6.02 x 2.11 x 8.56 3.05 x 11.10 13.49 x
1.1/2" 48.26 40 3.68 3.18 1.65 x 5.08 2.77 x 5.72 7.14 x
3" 88.9 80 5.49 x 2.11 x 7.62 3.05 x 8.89 11.13 x
10" 273.05 250 9.27 7.8 3.4 18.24 15.06 4.19 12.7 21.41 28.58 6.35
6" 168.27 150 7.11 x 2.77 x 10.97 3.4 x 14.27 18.26 x
2" 60.32 50 3.91 x 1.65 x 5.54 2.77 x 6.35 8.74 x
3/4" 26.67 20 2.87 2.41 1.65 x 3.91 2.11 x 4.32 5.56 x
8" 219.07 200 8.18 7.04 2.77 15.06 12.70 3.76 12.7 18.24 23.01 6.35
5" 141.3 125 6.55 x 5.77 x 9.53 3.4 x 12.70 15.88 x

Application Of API 5L X42 ERW Pipe

Application Of Api 5L X42 ERW Pipe

Applications

  • Boiler systems
  • Oil and gas Pipeline
  • Ship Building
  • Petrochemical processing plants
  • Water distribution systems
  • Fluid Transportation
  • Natural Gases Industry
  • Pulp and Paper




API 5L Grade X52 PSL1 Seamless Pipe Chemical Composition

Steel Grade (Steel Name)
% maximum
C b Si P Ti V S Mn b
X52N 0. 24 0 .40 0.025 0.04 0.07 0. 015 1.40
X52Q 0. 18 0. 45 0.025 0.04 0.05 0. 015 1.50
X52M 0.22 0.45 0.025 d d 0.015 1.40

API 5L Gr X52 HIC Pipe Mechanical Properties

Elongation

21 %




Yield Strength

52 KSi



Tensile Strength

66 Ksi



Yield-Tensile ratio

0.93



X52 Line Pipe Equivalent Chart

EN

1.0582



DIN

StE360.7



What are The Sueface Finishes Available For Grade X52 Seamless Pipes

  • End Finish
    • Threaded
    • Beveled
  • Surface Finish
    • Mill varnish
    • Oiled
    • 3LPP,3LPE
    • FBE

API 5L X52 Pipe HS Code

Grade API 5L X52 Pipe
HS Code 73051121

How Yaye Industrial Pipe Manufacturing Company Ensure Customer Satisfaction?

  • Customer Support
  • Quality Product
  • Quick Query Resolvance
  • On Time Deliveries
