ASTM A420 WPL6 Fittings

Home|ASTM A420 WPL6 Fittings

Popular Manufacturer of LTCS Elbow in China, At Resonable Cost

ASTM A420 WPL6 Fittings

Table of Content

pipe-fitting-table-of-content

Stockist of Carbon Steel ASTM A420 WPL6 Buttweld Fittings in Wenzhou, Check Various Types & Specification of A420 WPL6 Material

ASTM A420 WPL6 Fittings Specification

Fitting size icon

ASTM A420 WPL6 Fitting Sizes

  • Seamless Size : 1/2″ To 24″
  • Welded Size :24 To 96″
  • Buttweld Size: 1/2″ To 36″
fitting thickness icon

ASTM A420 WPL6 Common Thickness

  • Schedule : 80 To 120
  • Schedule : 160 To 180
  • Schedule 20 & 40
Pipe Testing

ASTM A420 WPL6 Welded Fittings Testing

  • Hardness Test
  • PMI Test
  • Chemical Analysis
  • Mechanical Testing
Standards

SA 420 Gr WPL6 Seamless Fittings Standards

  • ASME B16.25
  • ASME B16.28
Melting Point

WPL6 Elbow Melting Point

  • 1480–1526 °C
Density

A420 Tee Density

  • 7.8 g/cm³
Hardness

A420 WPL6 Reducer Hardness

  • 180-200 HB
life

ASTM A420 WPL6 Concentric Reducer life

  • Several years
pipe manufacturing process

WPL6 End Cap Manufacturing Process

  • Welding
  • Pushing
  • Forged
  • Casting
coating icon

A420 WPC Bend Types Of Coating

  • PE/ PTFE/ FBE coating
  • Back painting/li>
  • Anti rust
  • Zinc coatings
Origins

ASTM A420 WPL6 Welded Fittings Origins

  • Germany
  • Indonesia, India
  • China
  • Qatar
fittings type

Types of Welded Pipe Fittings

  • Pipe cross
  • Reducer,End cap
  • Elbow, Tee, Stub end
  • Pipe bend
Applications

Seamless Pipe Fittings Applications

  • Power Generation
  • Marine engineering
  • Sea water exchange
  • Chemical processing
Documentation

A420 WPL6 Butt Welding Fittings Documentation

  • Material traceability records
  • Raw material test reports
  • Heat treatment charts
  • Fumigation certificates
Process icon

A420 Welded Pipe Fittings Process

  • Bevelled End (BE)
  • Plain End (PE)
  • Threaded End (TE)
Methods

Methods of A420 WPC Bend

  • Seamless
  • Welded
  • Buttweld
pipe bending

ASTM A420 WPL6 Butt Welded Joint Bending

  • Thickness, Length
  • Straightness, Ovality
  • Inner diameter
  • Outer diameter
Disadvantages

A420 Tee Disadvantages

  • Very low hardenability
  • Higher Cost
  • Weldability
  • limited temperature performance
Packaging

A420 WPL6 Reducer Packaging

  • Wooden Box
  • Bubble Wraps
  • Bundled
Advantages

WPL6 End Cap Advantages

  • Strength
  • Easy to fabricate
  • Widely Application s
  • Lower costs

Types of ASTM A420 WPL6 Fittings


ASTM A420 WPL6 Fittings Supplier in China offers a variety of the commonly used fittings types.


A420 WPL6 Buttweld Fittings

A420 WPL6 Buttweld Fittings

ASTM A420 WPL6 Welded Fittings

ASTM A420 WPL6 Welded Fittings

SA 420 Gr WPL6 Seamless Fittings

SA 420 Gr WPL6 Seamless Fittings

WPL6 Elbow

WPL6 Elbow

A420 Tee

A420 Tee

A420 WPL6 Reducer

A420 WPL6 Reducer

ASTM A420 WPL6 Concentric Reducer

ASTM A420 WPL6 Concentric Reducer

WPL6 End Cap

WPL6 End Cap

A420 WPC Bend

A420 WPC Bend


Carbon Steel ASTM A420 WPL6 Pipe Fittings Dimensions Chart

ASTM A420 WPL6 Fittings Manufacturer in China offers a wide Range of Dimensions

Carbon Steel ASTM A420 WPL6 Pipe Fittings Dimensions Chart

  OD Elbows Short Returns Caps Reducers Radius Stub Ends Diam


Long 90deg

45deg 90deg Long Short Long Note 1 of Fillet Short of Lap
NPS DN D A B A O O K E K F H R F G
3/4 20 26.7 38 19 76 51 25 76 38 3 51 43
1 25 33.4 38 22 25 76 51 56 38 41 102 51 3 51 51
1/2 15 21.3 38 16 76 48 25 76 3 51 35
2 50 60.3 76 35 51 152 102 106 38 81 152 76 8 64 92
21/2 65 73.0 95 44 64 190 127 132 38 100 152 89 8 64 106
11/4 32 42.2 48 25 32 95 64 70 38 52 102 51 5 51 64
5 125 141.3 190 79 127 381 254 262 76 197 203 127 11 76 185
11/2 40 48.3 57 29 38 114 76 83 38 62 102 64 6 51 73
3 80 88.9 114 51 76 229 152 159 51 121 152 89 10 64 127
31/2 90 101.6 133 57 89 267 178 184 64 140 152 102 10 76 140
4 100 114.3 152 64 102 305 203 210 64 159 152 102 11 76 157
6 150 168.3 229 95 152 457 305 313 89 237 203 140 13 89 218

Dimension Chart Of ASTM A420 WPL6 Cap

NPS O.D Length Of (H1) Length Of (H)
1.1/4 42.2 38 38
1 33.4 38 38
18 457 229 203
1.1/2 48.3 38 38
2 60.3 44 38
20 508 254 229
2.1/2 73 51 38
3/4 26.7 25 25
3 88.9 64 51
10 273 152 127
3.1/2 101.6 76 64
12 323.8 178 152
4 114.3 76 64
8 219.1 127 102
1/2 21.3 25 25
5 141.3 89 76
22 559 254 254
6 168.3 102 89
14 355.6 191 165
16 406.4 203 178
24 610 305 267

Dimensions Of SA 420 Gr WPL6 Bend

Pipe Sizes Specification . Bauart 5 2,5D
Dia. [OD] Size CLR CLR CLR
219,1 200 - 510 -
355,6 350 - 850 -
60,3 50 125 - 151
48,3 40 110 - 212
323,9 300 - 775 -
88,9 80 - 205 222
114,3 100 - 270 286
76,1 65 - 175 190
26,9 20 110 - 67
33,7 25 110 - 84
42,4 32 110 - 106
508 500 - 1245 -
139,7 125 - 330 350
168,3 150 - 390 421
273 250 - 650 -
406,4 400 - 970 -

Reducer Weigth Chart Of SA 420 WPL6 Welded Fittings

Nominal Size SCH80 STD SCH160 SCH40 SCH20 SCH120
DN NPS
15 1/2 0.1 0.08 0.08
300 12 56.5 28.8 53.3 32.1 25.6 41.7
125 5 6 3.96 7.14 3.96
80 3 1.9 1.36 1.36
90 3 1/2 2.27 1.63 2.4 1.63
32 1 1/4 0.35 0.29 0.29
40 1 1/2 0.58 0.42 0.6 0.42
400 16 102 44.5 143 64.3 35.2 112
50 2 1.03 0.8 1.04 0.8
20 3/4 0.2 0.17 0.17
500 20 181 72.6 72.6
25 1 0.25 0.21 0.22 0.21
65 2 1/2 1.42 1.05 1.65 1.05
450 18 165 62.7 98.5 62.7
100 4 3.93 2.77 4.4 2.77
200 8 17.5 10.7 18.4 10.7 7.85 15
250 10 25.1 15.8 32.5 16.3 11.2 25.1
150 6 9.26 6.31 10.8 6.31
550 22 226 79.1 142 97
350 14 79 38.5 106 48.8 30.5 84.5
600 24 100 130

Size Range Of SA 420 Gr WPL6 Seamless Fittings

SA 420 Gr WPL6 fittings Tolerances
Size Off Plane P Off Angle Q
10 to 12 0.19 0.09
½ to 4 0.06 0.03
5 to 8 0.12 0.06
14 to 16 0.25 0.09
32 to 42 0.5 0.19
18 to 24 0.38 0.12
26 to 30 0.38 0.19
44 to 48 0.75 0.18

Pressure Ratings Table Of A420 Tee

Ratings Pressure Classes
150 300
1 1/4 - 2 inch. 1/4 - 1 inch. 2 1/2 - 3 inch.
(oF) (oC)
550 288 - 300 300 300
500 260 - 450 510 385
450 232 - 600 725 475
400 204 - 750 935 560
350 177 150 900 1150 650
300 149 185 1050 1360 735
250 121 225 1200 1575 825
200 93 265 1350 1785 910
-20 to 150 -29 to 66 300 1500 2000 1000

Elevated Temperatures Of SA 420 Gr WPL6 Fittings

DSI Temperatures
20 200
17.9 600
19 500
17.3 650
20 150
20 300
19.9 400
20 -20~100
16.8 700

Required Types of Impact Testing for SA 420 gr WPL6 Pipe Fittings?

Property Requirements
Impact Test Types Charpy V-notch
Minimum Energy Absorbed 15 ft-lb
Thickness 0.50 inches
Test Temp -50°F

Chemical Composition of SA 420 Gr WPL6 Buttweld Pipe Fittings

Carbon

≤0.30

Phosphorus

≤0.035

Sulfur

≤0.040

Silicon

0.15-0.40

Manganese

0.50-1.35

Molybdenum

≤0.12

Chromium

≤0.30

Nickel

≤0.40

SA 420 Gr WPL6 Seamless Fittings Mechanical Properties

ASTM A420 WPL6 Fittings Manufacturer in China offers Superior Mechanical Properties

Elongation

22 % min

Yield Strength

240 MPa

Tensile Strength

415-655 MPa


HS Code of ASTM A420 WPL6 Fittings

Product HS Code
ASTM A420 WPL6 Fittings 7307

Difference Between ASTM A234 WPB And ASTM A420 WPL6 Fittings

Difference Between ASTM A234 WPB And ASTM A420 WPL6 Fittings

ASTM A234 WPB Vs ASTM A420 WPL6

Property ASTM A234 WPB ASTM A420 WPL6
Yield Strength 35 ksi 35 ksi
Temperature Range -20°F to 750°F -50°F to 150°F
Elongation 20% 20%
Tensile Strength 70 ksi 60 ksi
Charpy V-Notch Impact Test Not required Required at -50°F (-45.6°C) for certain thicknesses
Wall Thickness Up to 4 inches (101.6 mm) Up to 2.5 inches (63.5 mm)
Chemical Properties Carbon , Manganese, etc. Carbon , Manganese , etc.


Buying Tips For ASTM A420 WPL6 Fittings

  • Consider Grades of steel
  • Certifications From organizations
  • Internal Diameter

What Types of Testing Are Performed For Yaye Industrial ASTM A420 WPL6 Fittings?

  • Hydrostatic test
  • Visual Inspection
  • Ultrasonic test
