ASTM A234 WP22 Fittings

Home|ASTM A234 WP22 Fittings

Manufacturer of SA 234 WP22 Buttweld Elbow in China,With Several Types

ASTM A234 WP22 Fittings

Table of Content

pipe-fitting-table-of-content

Supplier of Alloy Steel WP22 Buttweld Fittings in Wenzhou, used in pressure pipes and pressure vessels, Check Specification & Chemical composition.

ASTM A234 WP22 Fittings Specification

Fitting size icon

Alloy Steel WP22 Fittings Sizes

  • Seamless Size : 1/2" To 24"
  • Welded Size :24" To 96"
  • Buttweld Size: 1/2" To 36"
fitting thickness icon

SA 234 WP22 Reducer Common Thickness

  • Schedule : 80 To 160
  • Schedule 20 & 40
  • Schedule : XS To 180
Standards

Alloy Steel WP22 180 Deg Bend Standards

  • ANSI B16.25
  • ASME B16.9
  • ASME B16.28
Pipe Testing

Alloy Steel 3d Pipe Bend Testing

  • Ultrsonic Test
  • Chemical Analysis
  • PMI Test
  • Hyrdrostatic test
Density

Chrome Moly WP22 Pipe Elbow Density

  • 7.86 g/cm³
Melting Point

Alloy Steel WP22 Pipe Reducer Melting Point

  • 816 °C
life

SA 234 WP22 Buttweld Elbow life

  • 5 years
Hardness

ASTM A234 Alloy Steel WP22 Long Stub Hardness

  • 197 HBW
coating icon

Chrome Moly WP22 Pipe Elbow Types Of Coating

  • PE/ PTFE/ FBE coating
  • Anti rust
  • Zinc coatings
  • Back painting
fittings type

Types of Alloy Steel WP22 Short Radius Elbow

  • Elbow, Tee, Stub end
  • Reducer,End cap
  • Pipe cross
  • Pipe bend
Origins

Alloy Steel WP22 180 Deg Bend Origins

  • China
  • Germany
  • Indonesia, India
  • Qatar
pipe manufacturing process

Alloy Steel 3d Pipe Bend Manufacturing Process

  • Casting
  • Pushing
  • Welding
  • Forged
Documentation

A234 Wp22 Elbow Documentation

  • Fumigation certificates
  • Material traceability records
  • 100% Radiography Test Report
Applications

Alloy Steel 3d Pipe Bend Applications

  • Gas, Oil
  • Petrochemicals
  • Pharmaceuticals
  • Chemical Equipment
Advantages

SA 234 WP22 Buttweld Elbow Advantages

  • Handling Easy
  • Corrosion Resistant
  • Strength
  • Weldable
pipe bending

Alloy Steel WP22 End Cap Bending

  • Thickness, Length
  • Inner diameter
  • Straightness, Ovality
  • Outer diameter
Methods

Methods of Chrome Moly WP22 Pipe Elbow

  • Welded
  • Seamless
  • Buttweld
Disadvantages

Alloy Steel WP22 Buttweld Fittings Disadvantages

  • Sizing
  • Require Coatings
  • Machining
  • Corrosions
Packaging

Alloy Steel WP22 Short Radius Elbow Packaging

  • Bundled
  • Wooden Box
  • Bubble Wraps
  • Carton
Process icon

SA 234 WP22 Buttweld Elbow Process

  • Bevelled End (BE)
  • Threaded End (TE)
  • Plain End (PE)

Types of ASTM A234 WP22 Fittings


ASTM A234 WP22 Fittings Supplier in China offers different types of generally used fittings


Alloy Steel WP22 Buttweld Fittings

Alloy Steel WP22 Buttweld Fittings

Chrome Moly WP22 Elbow

Chrome Moly WP22 Elbow

A234 Wp22 Welded Fittings

A234 Wp22 Welded Fittings

Chrome Moly WP22 Seamless Fittings

Chrome Moly WP22 Seamless Fittings

Alloy Steel WP22 Tee

Alloy Steel WP22 Tee

ANSI A234 Alloy Steel WP22 End Cap

ANSI A234 Alloy Steel WP22 End Cap

A234 Wp22 Concentric Reducer

A234 Wp22 Concentric Reducer

Alloy Steel WP22 Bend

Alloy Steel WP22 Bend

Chrome Moly WP22 Reducer

Chrome Moly WP22 Reducer


SA 234 WP22 Buttweld Elbow Weight Chart

NPS Weight (KG) Weight (LBS)
1/2 0.04 0.09
3/4 0.04 0.09
1 0.11 0.25
2 0.37 0.81
1.1/2 0.18 0.4
3 1.19 2.63
24 107.95 238
30 166.47 367
14 36.29 80
2.1/2 0.79 1.75
16 45.36 100
1.1/4 0.17 0.38
18 57.15 126
36 240.86 531
5 3.4 7.5
3.1/2 1.59 3.5
4 2.04 4.5
6 5.44 12
12 28.12 62
8 10.43 23
10 19.5 43
22 89.36 197
20 72.57 160
26 124.74 275

Sizes Of SA 234 WP22 Buttweld Elbow

ASTM A234 WP22 Fittings Manufacturer In china Offers multiple sizes of fitting

NPS Schedule No Wall Thickness inch mm OD In inch mm Weight lb/ft kg/m
1/8 6 5S ... 0.405 10.3 ...
3/8 10 80S 0.126 3.20 0.675 17.1 0.74 1.10
6 150 5S 0.109 2.77 6.625 168.3 7.59 11.31
1-1/2 40 5S 0.065 1.65 1.900 48.3 1.28 1.90
1/4 8 10S 0.065 1.65 0.540 13.7 0.33 0.49
3/8 10 5S ... 0.675 17.1 ...
1/2 15 5S 0.065 1.65 0.840 21.3 0.54 0.80
1-1/4 32 5S 0.065 1.65 1.660 42.2 1.11 1.65
2 50 5S 0.065 1.65 2.375 60.3 1.61 2.39
3 80 5S 0.083 2.11 3.500 88.9 3.03 4.52
2-1/2 65 5S 0.083 2.11 2.875 73 2.48 3.69
4 100 5S 0.083 2.11 4.500 114.3 3.92 5.84
3-1/2 90 5S 0.083 2.11 4.000 101.6 3.48 5.18
3/4 20 80S 0.154 3.91 1.050 26.7 1.48 2.20
1/2 15 80S 0.147 3.73 0.840 21.3 1.09 1.62
1 25 5S 0.065 1.65 1.315 33.4 0.68 1.02
5 125 5S 0.109 2.77 5.563 141.3 6.36 9.46

Schedule Chart Of Alloy Steel WP22 Pipe Reducer

NPS Sch 40S Sch 10S Sch 80S
Ecc Reducer Con Reducer Reducing/ Unequal Tee Ecc Reducer Con Reducer Reducing/ Unequal Tee Ecc Reducer Con Reducer Reducing/ Unequal Tee
200x150 6.74 6.74 18.82 3.19 3.19 14.08 10.12 10.12 25.31
80x.50 1.00 1.00 2.91 0.55 0.55 1.56 1.79 1.79 3.91
50x40 0.45 0.45 1.15 0.31 0.31 0.76 0.59 0.59 1.43
40x.25 0.26 0.26 0.76 0.19 0.19 0.60 0.34 0.34 0.90
150x100 4.07 4.07 11.94 1.96 1.96 7.10 5.96 5.96 11.97
50x25 0.40 0.40 1.10 0.28 0.28 0.73 0.54 0.54 1.37
100x80 1.74 1.74 4.64 0.87 0.87 3.04 2.33 2.33 6.79
100x50 1.50 1.50 4.48 0.78 0.78 2.94 1.95 1.95 6.55
150x80 3.95 3.95 9.68 1.82 1.82 6.86 5.51 5.51 11.57
200x100 6.55 6.55 17.98 3.01 3.01 13.46 9.23 9.23 24.18

Dimension Chart Chrome Moly WP22 Fittings

NPS O.D. 45 Deg Elbow 90 Deg Elbow 180 Deg Return
(inch) Long Radius Short Radius Long Radius Long Radius
(mm) (inch) Radius (inch) Center - Face (inch) Center - Face (inch) Center - Face (inch) Back - face (inch) Center - Center (inch)
1 33.4 1.315 7/8 1 1 1/2 2 3/16 3
1 1/4 42.2 1.660 1 1 1/4 1 7/8 2 3/4 3 3/4
3/4 26.7 1.050 7/16 – 1 1/8 1 11/16 2 1/4
1/2 21.3 0.840 5/8 – 1 1/2 1 7/8 2
1 1/2 48.3 1.900 3 1 1/8 1 1/2 2 1/4 3 1/4 4 1/2
2 1/2 73.0 2.875 5 1 3/4 2 1/2 3 3/4 5 3/16 7 1/2
3 88.9 3.500 6 2 3 4 1/2 6 1/4 9
3 1/2 101.6 4.000 7 2 1/4 3 1/2 5 1/4 7 1/4 10 1/2
2 60.3 2.375 4 1 3/8 2 3 4 3/16 6
4 114.3 4.500 8 2 1/2 4 6 8 1/4 12
10 273.1 10.750 15 6 1/4 10 15 20 3/8 30
8 219.1 8.625 12 5 8 12 16 5/16 24
5 141.3 5.563 10 3 1/8 5 7 1/2 10 5/16 15
6 168.3 6.625 12 3 3/4 6 9 12 5/16 18
12 323.9 12.750 18 7 1/2 12 18 24 3/8 36

Thickness Chart ASTM A234 Alloy Steel WP22 Cap

DN Schedule Nn OD inch mm Thick inch mm Weight lb/ft kg/m
1/8- 6 10S 0.405- 10.3 0.049- 1.24 0.19- 0.28
1/8- 6 5S 0.405- 10.3 ... ...
1/8- 6 80S 0.405- 10.3 0.095- 2.41 0.31- 0.47
1/8- 6 40S 0.405- 10.3 0.068- 1.73 0.24- 0.37
1/4- 8 10S 0.540- 13.7 0.065- 1.65 0.33- 0.49
1/4- 8 5S 0.540- 13.7 ... ...
1/4- 8 80S 0.540- 13.7 0.119- 3.02- 0.54- 0.80
1/4- 8 40S 0.540- 13.7 0.088- 2.24 0.43- 0.63
3/8- 10 5S 0.675- 17.1 ... ...
3/8- 10 40S 0.675- 17.1 0.091- 2.31 0.57- 0.84
3/8- 10 10S 0.675- 17.1 0.065- 1.65 0.42- 0.63
3/8- 10 80S 0.675- 17.1 0.126- 3.20 0.74- 1.10
1/2- 15 5S 0.840- 21.3 0.065- 1.65 0.54- 0.80
1/2- 15 40S 0.840- 21.3 0.109- 2.77 0.85- 1.27
1/2- 15 10S 0.840- 21.3 0.083- 2.11 0.67- 1.00
1/2- 15 80S 0.840- 21.3 0.147- 3.73 1.09- 1.62
3/4- 20 5S 1.050- 26.7 0.065- 1.65 0.68- 1.02
3/4- 20 40S 1.050- 26.7 0.113- 2.87 1.13- 1.69
3/4- 20 10S 1.050- 26.7 0.083- 2.11 0.86- 1.28
1- 25 5S 1.315- 33.4 0.065- 1.65 0.68- 1.02
2- 50 10S 2.375- 60.3 0.109- 2.77 2.64- 3.93
2- 50 40S 2.375- 60.3 0.154- 3.91 3.66- 5.44
1- 25 80S 1.315- 33.4 0.179- 4.55 2.17- 3.24
1- 25 40S 1.315- 33.4 0.133- 3.38 1.68- 2.50
1-1/4- 32 40S 1.660- 42.2 0.140- 3.56 2.27- 3.39
1-1/4- 32 80S 1.660- 42.2 0.191- 4.85 3.00- 4.47
1-1/2- 40 5S 1.900- 48.3 0.065- 1.65 1.28- 1.90
1-1/4- 32 5S 1.660- 42.2 0.065- 1.65 1.11- 1.65
3/4- 20 80S 1.050- 26.7 0.154- 3.91 1.48- 2.20
1- 25 10S 1.315- 33.4 0.083- 2.11 0.86- 1.28
1-1/4- 32 10S 1.660- 42.2 0.109- 2.77 1.81- 2.69
1-1/2- 40 10S 1.900- 48.3 0.109- 2.77 2.09- 3.11
1-1/2- 40 40S 1.900- 48.3 0.145- 3.68 2.72- 4.05
1-1/2- 40 80S 1.900- 48.3 0.200- 5.08 3.63- 5.41
2- 50 5S 2.375- 60.3 0.065- 1.65 1.61- 2.39
2- 50 80S 2.375- 60.3 0.218- 5.54 5.03- 7.48
2-1/2- 65 5S 2.875- 73 0.083- 2.11 2.48- 3.69
2-1/2- 65 10S 2.875- 73 0.120- 3.05 3.53- 5.26
2-1/2- 65 40S 2.875- 73 0.203- 5.16 5.80- 8.63
2-1/2- 65 80S 2.875- 73 0.276- 7.01- 7.67- 11.41
3- 80 5S 3.500- 88.9 0.083- 2.11 3.03- 4.52
3- 80 10S 3.500- 88.9 0.120- 3.05 4.34- 6.46
3- 80 40S 3.500- 88.9 0.216- 5.49 7.58- 11.29
3-1/2- 90 10S 4.000- 101.6 0.120- 3.05 4.98- 7.41
3-1/2- 90 40S 4.000- 101.6 0.226- 5.74 9.12- 13.57
3- 80 80S 3.500- 88.9 0.300- 7.62 10.26- 15.27
3-1/2- 90 5S 4.000- 101.6 0.083- 2.11 3.48- 5.18
4- 100 10S 4.500- 114.3 0.120- 3.05 5.62- 8.37
4- 100 40S 4.500- 114.3 0.237- 6.02 10.80- 16.08
3-1/2- 90 80S 4.000- 101.6 0.318- 8.08 12.52- 18.64
4- 100 5S 4.500- 114.3 0.083- 2.11 3.92- 5.84
6- 150 5S 6.625- 168.3 0.109- 2.77 7.59- 11.31
6- 150 10S 6.625- 168.3 0.134- 3.40 9.30- 13.83
6- 150 40S 6.625- 168.3 0.280- 7.11 18.99- 28.26
6- 150 80S 6.625- 168.3 0.432- 10.97 28.60- 42.56
4- 100 80S 4.500- 114.3 0.337- 8.56 15.00- 22.32
5- 125 80S 5.563- 141.3 0.375- 9.53 20.80- 30.97
5- 125 5S 5.563- 141.3 0.109- 2.77 6.36- 9.46
5- 125 10S 5.563- 141.3 0.134- 3.40 7.78- 11.56
5- 125 40S 5.563- 141.3 0.258- 6.55 14.63- 21.77

ANSI A234 Alloy Steel WP22 Buttweld Fittings Tolerance Chart

Normal Pipe Size Center-to-End Dimensions Over-all Len F Over-all Len H I. D. at End O. D. at Bevel
1/2 to 2-1/2 +/- 0.06 +/- 0.12 +/- 0.06 +0.06
-0.03
3 to 3-1/2 +/- 0.06 +/- 0.12 +/- 0.06 +/- 0.06 +/- 0.06
20 to 24 +/- 0.09 +/- 0.25 +/- 0.09 +/- 0.19 +0.25
-0.12
4 +/- 0.06 +/- 0.12 +/- 0.06 +/- 0.06 +/- 0.06
-0.19
32 to 48 +/- 0.19 +/- 0.38 +/- 0.19 +/- 0.19 +0.25
-0.19
26 to 30 +/- 0.12 +/- 0.38 +/- 0.19 +/- 0.19 +0.25
5 to 8 +/- 0.06 +/- 0.25 +/- 0.06 +/- 0.06 +/- 0.06
10 to 18 +/- 0.09 +/- 0.25 +/- 0.09 +/- 0.12 +0.16
-0.19

Pressure Temperature Ratings Of Chrome Moly WP22 Pipe Elbow

Diameter (IN) Outside Diameter (mm) Nominal Wall Thickness (IN) Pipe & Reducers (kPa) One Reduction (kPa) L.R. Elbows Smooth Flow (kPa) Mitred Elbows (kPa) Tees (kPa) Laterals (kPa)
14 505 0.078 450 380 250 155 55 21
14 825 0.120 740 620 410 255 14 20
11 660 0.125 595 490 325 200 105 34
14 535 0.109 485 405 265 165 100 114
14 710 0.134 640 530 350 215 14 20
11 710 0.120 640 535 355 220 105 32
14 405 0.125 365 305 200 125 58 28
5 570 0.125 515 425 285 175 5 5
14 340 0.125 305 260 168 105 58 28
12 450 0.134 405 345 225 140 12 28
12 290 0.125 260 225 140 90 11 32
6 475 0.125 430 365 235 145 6 6
12 550 0.134 495 420 275 170 105 34
14 500 0.134 530 450 295 180 14 20
12 260 0.109 230 200 125 80 58 28
12 335 0.125 300 260 160 105 10 10.750
12 360 0.134 320 275 170 110 105 42
11 790 0.125 710 595 390 245 11 32
12 365 0.125 325 280 180 110 200 219
12 420 0.125 375 320 210 130 105 34

Chemical Composition of Alloy Steel WP22 180 Deg Bend

Chromium (Cr)

1.90–2.60

Manganese (Mn)

0.30–0.60

Silicon (Si)

0.5

Sulfur (S)

0.04

Phosphorus (P)

0.04

Carbon (C)

0.05–0.15

Mechanical Properties Alloy Steel WP22 Cl1 Buttweld Fittings

Elongation

20%

Tensile Strength

48 kSi MPa

Yield Strength

30 KSi


Chrome Moly WP22 Cl3 Buttweld Fittings Mechanical Qualities

ASTM A234 WP22 Fittings Manufacturer In China Offers Fittings With Excellent Mechanical properties

Yield Strength

45 KSi

Elongation

20 %

Tensile Strength

75 KSi


Equivalent Standards Of A234 WP22 Bend


DIN

2618

GOST

17376

17378


JIS

B2312



HS Code of ASTM A234 WP22 Alloy Steel Fittings

Product HS Code
ASTM A234 WP22 Fittings 73079990

Difference Between A234 WP22 Swage and A234 Wp22 Reducer

A234 Wp22 Reducer A234 WP22 Swage
Straight or concentric shape Conical Shape
reduces the size of the pipe to a smaller bore reduces pipe size to a smaller bore similar to reducers
connecting buttweld pipes to screwed welded pipes connecting buttweld pipes to socket welded pipes
Difference Between A234 WP22 Swage and A234 Wp22 Reducer

How Does Yaye Industrial Ensure ASTM A234 WP22 Fittings quality?

  • Premium Material
  • Superior Coating
  • Finishings

Copyright © 2025 Yaye Industrial | All rights reserved.
