ASTM A352 LCB Valve Manufacturer in China

Table of Content

ASTM A352 LCB valve Specification
Types of ASME SA 352 Lcb Valve
Thermal Properties of ASME SA 352 Lcb Valve
Equivalent Grades Of ASTM A352 gr. LCB Swing Check Valves
Mechanical Properties Of A352 LCC Valves
Chemical Composition Of ASTM A352 gr. LCB Swing Check Valves
Applications of ASME SA 352 LCB Valve

A352 LCC Valves Manufacturer in China, Size Ranging From 1/4 to 24 inch, Check Specification

ASTM A352 LCB valve Specification

ASTM A352 LCB Valve Sizes

2" to 48"

A352 LCC Valves Standards

ASME B16.34

SA 352 Grade LCB ball valve End Connection

Flanged
Buttweld
Socket weld
Threaded

UNS J03003 Gate Valve Pressure Rating

class 150 to 2500

ASTM A352 gr. LCB Swing Check Valves Testing Methods

Cryogenic Testing
Fire Testing
Shell Testing
Seat Testing

ASME SA 352 Lcb Valve Operation

Manual
Pneumatic
Electric

SA 352 Grade LCB ball valve Seal Types

PTFE
FKM
NBR
CSM

Manufacturers Offers of UNS J03003 Gloabe Valve

Rigid quality control
Flexible payment methods
Professional production equipment
Service support

ASTM A352 gr. LCB Check Valve Temperature

-28°C To +180°C

Nominal Diameter of A352 LCC Lift Check Valve

DN40-DN300 handle lever
DN350-DN1200 gear box

Types of ASME SA 352 Lcb Valve

ASTM A352 LCB Valve

SA 352 Grade LCB Ball valve

A352 Butterfly Valves

A352 LCB Low Temperature Swing Plug Valves

Low Temperature Carbon Steel Lf2 Check Valves

A352 LCB Carbon Steel Gate Valve

Diaphragm Valves A352 LCB

SA 352 Grade LCB Fire Safe Design Ball Valve

ASTM A352 Lift Check Valve

Get SA 352 Grade LCB ball valve With best quality of Packing, Check Check Thermal Properties

Thermal Properties of ASME SA 352 Lcb Valve

PROPERTY	VALUES
Melting point	1380 - 1514 °C
Thermal conductivity	36 - 54 W/(m·K) at 20 °C
Max service temperature	500 °C
Specific heat capacity	465 - 483 J/(kg·K) at 20 °C
Coefficient of thermal expansion	1.32E-5 1/K at 20 °C

Equivalent Grades Of ASTM A352 gr. LCB Swing Check Valves

UNS Number (Cast)

J03003

AISI

1030

ASTM

A352

ASME

SA352

UNS Number (Wrought)

G10300

Mechanical Properties Of A352 LCC Valves

Reduction of Area

35% Min

Tensile Strength

65 - 90 ksi

Elongation at 2 in

24% Min

Yield Strength

35 ksi Min

Chemical Composition Of ASTM A352 gr. LCB Swing Check Valves

Manganese

1.00% Max

Silicon

0.60% Max

Phosphorus

0.04% Max

Sulfur

0.045% Max

Copper

0.30% Max

Carbon

0.30% Max

Chromium

0.50% Max

Nickel

0.50% Max

Applications of ASME SA 352 LCB Valve
