SA105N Ball Valve Sizes
1/4"- 24"
A105N Check Valve Features
ASTM A105 Globe Valves Standards
ASME B16.34
ASME B16.10
Connection of ASTM A105 Carbon Steel Ball Valve
Types of ASTM A105 Valve
A105N Gate Valve Operation
ASTM A105 3 Way Ball Valve Media
SA105N Trunnion Type Mountain Ball Valve Pressure Rating
Class 150 to 2500
API 6D A105 Globe Valve Temperature
-10°C to 120°C
ASTM A105 Carbon Steel Lift Check Valve End Connection
Dimension Chart Of ASTM A105 Carbon Steel Valves
| Size | L | D | W | H | J | B | NPT | Weight |
|---|---|---|---|---|---|---|---|---|
| IN | mm | mm | mm | mm | mm | mm | IN | Kg |
| 3/4 | 111 | 18 | 160 | 75 | 12.7 | 27.2 | 3/4" | 2.5 |
| 1/2 | 92 | 14 | 130 | 65 | 9.6 | 21.8 | 1/2" | 1.7 |
| 1 | 127 | 24 | 220 | 80 | 12.7 | 33.9 | 1* | 4.5 |
| 1-1/2 | 152 | 38 | 250 | 110 | 12.7 | 48.8 | 1-1/2" | 8.8 |
| 1-1/4 | 140 | 30 | 250 | 100 | 12.7 | 42.7 | 1-1/4" | 7 |
| 2 | 152 | 48 | 290 | 125 | 15.7 | 61.2 | 10 |
ASTM A105 Globe Valves
A105N Check Valve
ASTM A105 Ball Valve
ASTM A105 Carbon Steel Lug Type Butterfly Valve
ASTM A105 2 Piece Design Ball Valve
ASTM A105 Carbon Steel Trunnion Type Mountain Ball Valve
ASTM A105 Carbon Steel Swing Check Valve
SA105N Lift Check Valve
A105n Butterfly Valve
Chemical Composition of SA105N Butterfly Valve
Equivalent Grade Of ASTM A105 Carbon Steel 1 Piece Design Ball Valve
UNS
K03504
EN
EN 1.0460
ASTM
A105
Mechanical Properties of ASTM A105 Swing Check Valve
Hardness
187
Density
7.8 g/cm³
Elogation
22 %
Tensile Strength
485 Mpa
Difference between SA105N Gate Valve and Globe Valve
| Gate Valve | Globe Valves |
|---|---|
| The gate valve comes with a disc located between seats which help it move at a right angle | It comes with a rising stem which enables flow direction changes and the rate of high pressure drop |
| Disc moves parallel to right angle | Disc moves parallel to flow |
What Makes Yaye Industrial Better Than Other ASTM A105 Valve Companies In Wenzhou?
