ASTM A182 F51 UNS S32205 Flanges

Home|ASTM A182 F51 UNS S32205 Flanges

Trusted Manufacturer of SA 182 Grade F51 Bilnd Flanges in China, With PMI Test

ASTM A182 F51 UNS S32205 Flanges

Table of Content

Flanges-table

ASTM A182 F51 UNS S32205 Flanges Specification

Flange Sizes

UNS S32205 Flange Sizes

  • NPS: 1/2″ to 48″
  • 15NB – 1200NB
  • PN 2.5 – PN 400
Flange Standards

ASTM A182 F51 Weld Neck Flange Standards

  • ASME B16.47 Series A & B
  • MSS SP44
  • ASME B16.5
Flange Threads

UNS S32205 Weld Neck Flange Threads

  • NPT, MNPT
  • FNPT
  • BSPT
  • BSPP
Flanges Process

ASTM A182 F51 Orifice Flanges Process

  • Casting
  • Cutting
  • Rolling
  • Forging
Flange Schedule

UNS S32205 Slip On Flange Schedule

  • Sch 5 to XXS
Pressure Types

Duplex 2205 Weld Neck Flange Pressure Types

  • CLASS 600 To 900
  • CLASS 300 to 400
  • CLASS 1500 to 2500
  • CLASS 125 to 150
Advantages

ASTM A182 F51 Threaded Flange Advantages

  • Mechanical strength
  • High tensile strength
  • Weldability
  • Corrosion Resistance
Disadvantages

Disadvantages of UNS S32205 Socket Weld Flange

  • moderate temperatures
  • Pressure ratings
  • Limited flexibility
  • Brittle Transition
Testing Methods

UNS S32205 Socket Weld Flange Testing Methods

  • Pressure
  • PMI
  • Tensile
  • Hardness test
Features

ASTM A182 F51 Flanges Features

  • Corrosion resistance
  • Sizes
  • End connections
  • Weldability
flange Face

Duplex 2205 Slip on Flange Face

  • RTJ
  • FF
  • RF
  • T&G
Origin

UNS S32205 Spectacle Blind Flanges Origin

  • Indian /Uae
  • China
  • Thailand
  • Spain / Italy
Certificates

Certificates of WNR 1.4462 Weld Neck Flange

  • 100% Radiography Test
  • Third Party Inspection
  • MTC BS EN 10204 3.1/ 3.2
  • NACE MR0175
Density & Temperature

Duplex 2205 Threaded Flange Density & Temperature

  • Melting Point : 1385–1443°C.
  • Density : 7.8 g/cm³
  • Working Temp : 300°C (572°F)
  • Forging Temp : 1100–1250°C

Types of A694 Gr F51 Flanges


ASTM A182 F51 UNS S32205 Flanges

ASTM A182 F51 UNS S32205 Flanges

UNS S32205 Socket Weld Flange

UNS S32205 Socket Weld Flange

WNR 1.4462 Plate Flange

WNR 1.4462 Plate Flange

ASTM A182 F51 UNS S32205 Orifice Flanges

ASTM A182 F51 UNS S32205 Orifice Flanges

Duplex 2205 Slip On Flange

Duplex 2205 Slip On Flange

UNS S32205 Spectacle Blind Flanges

UNS S32205 Spectacle Blind Flanges

ASTM A182 F51 Threaded Flange

ASTM A182 F51 Threaded Flange

UNS S32205 Weld Neck Flange

UNS S32205 Weld Neck Flange

ASTM A182 F51 Lap Joint Flanges

ASTM A182 F51 Lap Joint Flanges


Supplier of UNS S32205 Duplex Steel Flanges with superior Corrosion Resistance & Refer 2205 Duplex Steel Flanges UNS S32205 Specification & Equivalent


Dimensions Chart Of ASTM A182 F51 UNS S32205 Flanges

ASTM A182 F51 UNS S32205 Flanges Manufacturer In China Provides A Wide Variety Of Dimensions.

ASTM A182 F51 UNS S32205 Flanges Dimensions

NOMINAL SIZE RF DIA. (R) MIN. THICK (T) OUTSIDE DIA (OD) DIA OF HOLES NO. OF BOLT HOLES DIA. HUB BASE (HB) WN LTH (WL) BOLT CIRCLE (BC) SO LTH (SL) SO BORE ID (SB) DIA. OF HUB TOP (HT) WN BORE ID (WB)
24 27.25 1.81 32.00 1.38 20 26.12 5.94 29.50 3.19 24.25 24.00 23.25
1⁄2 1.38 0.38 3.50 0.62 4 1.19 1.81 2.38 0.56 0.88 0.84 0.62
22 25.25 1.75 29.50 1.38 20 24.25 5.82 27.25 3.07 22.22 22.00 21.25
3⁄4 1.69 0.44 3.88 0.62 4 1.50 2.00 2.75 0.56 1.09 1.05 0.82
20 23.00 1.62 27.50 1.25 20 22.00 5.62 25.00 2.81 20.20 20.00 19.25
1 2.00 0.50 4.25 0.62 4 1.94 2.12 3.12 0.62 1.36 1.32 1.05
31⁄2 5.50 0.88 8.50 0.75 8 4.81 2.75 7.00 1.19 4.07 4.00 3.55
18 21.00 1.50 25.00 1.25 16 19.88 5.44 22.75 2.62 18.18 18.00 17.25
4 6.19 0.88 9.00 0.75 8 5.31 2.94 7.50 1.25 4.57 4.50 4.03
11⁄4 2.50 0.56 4.62 0.62 4 2.31 2.19 3.50 0.75 1.70 1.66 1.38
5 7.31 0.88 10.00 0.88 8 6.44 3.44 8.50 1.38 5.66 5.56 5.05
16 18.50 1.38 23.50 1.12 16 18.00 4.94 21.25 2.44 16.16 16.00 15.25
11⁄2 2.88 0.62 5.00 0.62 4 2.56 2.38 3.88 0.81 1.95 1.90 1.61
8 10.62 1.06 13.50 0.88 8 9.69 3.94 11.75 1.69 8.72 8.63 7.98
14 16.25 1.31 21.00 1.12 12 15.75 4.94 18.75 2.19 14.14 14.00 13.25
2 3.62 0.69 6.00 0.75 4 3.06 2.44 4.75 0.94 2.44 2.38 2.07
12 15.00 1.19 19.00 1.00 12 14.38 4.44 17.00 2.12 12.88 12.75 12.00
6 8.50 0.94 11.00 0.88 8 7.56 3.44 9.50 1.50 6.72 6.63 6.07
21⁄2 4.12 0.81 7.00 0.75 4 3.56 2.69 5.50 1.06 2.94 2.88 2.47
10 12.75 1.12 16.00 1.00 12 12.00 3.94 14.25 1.88 10.88 10.75 10.02
3 5.00 0.88 7.50 0.75 4 4.25 2.69 6.00 1.12 3.57 3.50 3.07

UNS S32205 Weld Neck Flange Weight Chart

STANDARD NO. OF BOLTS DIA OF BOLT HOLE CLASS BOLT SIZE BOLT CIRCLE DIA DIA
ISO 7005 (DIN) 4 16 PN20 M14 60.5 90
4 14 PN40 M12 65 95
4 14 PN10 M12 65 95
4 14 PN25 M12 65 95
4 14 PN16 M12 65 95
4 11 PN6 M10 55 80
AS4087 4 14 PN14 M12 67 95
ANSI B16.5 4 16 ANSI 600 13 67 95
4 22 ANSI 1500 19 83 121
4 16 ANSI 300 13 67 95
4 22 ANSI 900 19 83 121
4 16 ANSI 150 13 60 89
AS 2129 4 14 TABLE E 13 67 95
4 14 TABLE D 13 67 95
4 17 TABLE J 16 83 114
4 14 TABLE F 13 67 95
4 17 TABLE H 16 83 114
4 14 TABLE C 13 67 95

Pressure Rating Class Of ASTM A182 F51 Lap Joint Flanges

ASTM A182 F51 UNS S32205 Flanges Manufacturer In China Provides Flanges With Pressure Ratings Ranging From 150 To 2500 Psi

TEMP. ℃ PRESSURE-TEMP RATING FOR ASME B16.47 BY CLASS, BAR
400 900 75 300 600 150
150 61.2 137.8 7.9 45.9 91.9 15.8
300 51.8 116.6 5.1 38.9 77.7 10.2
50 68.9 155.1 9.8 51.7 103.4 19.5
250 53.9 121.4 6.0 40.5 80.9 12.1
100 67.5 152.0 8.8 50.7 101.3 17.7
200 56.9 128.0 6.9 42.7 85.3 13.8
-29 to 38 68.9 155.1 10.0 51.7 103.4 20.0
TEMP, ℃ PRESSURE-TEMP RATING FOR ASME B16.47 BY CLASS, BAR
400 2500 900 150 600 1500 300
150 61.2 382.7 137.8 15.8 91.9 229.6 45.9
300 51.8 323.8 116.6 10.2 77.7 194.3 38.9
50 68.9 430.9 155.1 19.5 103.4 258.6 51.7
250 53.9 337.2 121.4 12.1 80.9 202.3 40.5
100 67.5 422.2 152.0 17.7 101.3 253.3 50.7
200 56.9 355.4 128.0 13.8 85.3 213.3 42.7
-29 to 38 68.9 430.9 155.1 20.0 103.4 258.6 51.7

Equivalent Grades of UNS S32205 Socket Weld Flange

UNS

S32205

WERKSTOFF NR.

1.4462



Duplex 2205 Slip On Flange Chemical Composition

ASTM A182 F51 UNS S32205 Flanges Manufacturer In China Provides Accurate Chemical Composition Of Flanges

PHOSPHORUS

0.02

IRON

0.03

NITROGEN

0.03

SULFER

0.14 - 0.2

CARBON

1.0

SILICON

2.0

MANGANESE

3.0 - 3.5

CHROMIUM

4.5 - 6.5

MOLYBDENUM

22.0 - 23.0

Mechanical Properties of UNS S32205 Spectacle Blind Flanges

Yield Strength

Psi - 80000 , MPa - 550

Tensile Strength

Psi - 116000 , MPa - 800

Elongation

15 %


Applications Of ASTM A182 F51 UNS S32205 Flanges

ASTM A182 F51 UNS S32205 Flangess Applications


Difference Between ASTM A182 F51 UNS S32205 Flanges VS Cupro Nickle Forged Flanges

ASTM A182 F51 UNS S32205 flanges Cupro nickel forged flanges
Manufacturing Hot forging process Flange forging
Material 13% chromium alloy steel Copper-nickel alloy
Properties Resistant to stress corrosion cracking Resistant to seawater corrosion
Applications High temperature service Maritime applications
Difference ASTM A182 F51 UNS S32205 Flanges VS Cupro Nickle Forged Flanges

Why Are Yaye Industrial Wenzhou Astm A182 F51 Uns S32205 Flanges So Durable ?

  • Chemical composition
  • Protective layer
  • Highly Weldability
  • High-temperature Environments
  • Offshore Oil And Gas Industry
